Forced mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance will be failed
Face mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance is valid
Max.3000 faces capacity and Max.3000 cards
Supports TCP/IP
Face Recognition Terminal, 4.3-inch LCD touch screen,2 Mega pixel wide-angle lens,Built-in M1 card reading module
Supports ISUP5.0, ISAPI
Configuration via the web client
Face recognition. Distance: 0.3 m to 1.5 m
Two-way audio with client software, indoor station, and main station
Duration ＜ 0.2 s/User
Accuracy rate ≥ 99%; IP65


Display
Dimensions4.3-inch
TypeLCD
Operation methodCapacitive touch screen

Video
FOVHFOV = 41.5°; VFOV = 75.5°; DFOV = 87°
Pixel2 MP (video stream: 720P)
Lens× 2

Audio
Tone qualityNoise suppression and echo cancellation

Network
Wired network10 M/100 M/1000 M self-adaptive

Interface
Network interface1
RS-4851
Wiegand1
Lock output1
Exit button1
Door contact input1
Power interface2-pin

Capacity
Card capacity3,000
Face capacity3,000
Event capacity150,000

Authentication
Card typeM1 card
Card reading frequency13.56MHz
Face recognition duration＜ 0.2 s
Face recognition accuracy rate＞99%
Face recognition distance0.3 to 1.5 m

General
buttonTouch Screen
Power supply method2 pin connecter
Power supply12 VDC, 2 A. (power adapter not included)
Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
Working humidity0 to 90% (No condensing)
Dimensions172.5 mm × 83.2 mm × 22.7 mm (6.79" × 3.27" × 0.89")
InstallationSurface mounting
LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil)
PlatformHik-ProConnect and HikCentral Professional

Function
Face anti-spoofingSupport
Audio promptSupport
Time synchronizationSupport

Standalone access control fingerprint terminal
LCD display screen
3,000 fingerprints, 3,000 cards and 100,000 events storage
Built-in card reader for EM/Mifare1 card(optional)
Communication via TCP/TP and Wi-Fi
RS-485, wiegand interface
EHome for public network communication
Alarm input and output interface
Multiple time attendance status
General
Communication InterfaceTCP/IP, RS-485 (For Secure Door Control Unit), Wiegand Output (W26/W34) and Input (Wiegand 26/34)
Working Temperature-10 ° C to 55 ° C (14 ° F to 131 ° F)
Power Supply12 VDC/2 A
Audio1 Buzzer and 1 Loudspeaker
LED IndicatorPower/Status (Red/Green)
LCD Screen2.4-inch (320 × 240 LCD-TFT Display Screen)
Fingerprint CapacityUp to 3000 Fingerprints; Up to 10 Fingerprints for Each Person
StorageUp to 3000 Valid Cards;Up to 100,000 Event Records; Up to 150,000 Attendance Records
Card Reading ModeNot Support
Input InterfaceExit Button × 1, Door Sensor × 1 and Alarm Input × 1
Output InterfaceRelay (Lock Output) × 1, and Alarm Output × 1
Operating SystemLinux
Fingerprint Comparing Mode1:1 and 1:N, N=3000
Card Reading Response Duration< 1 s
Fingerprint Authentication Duration< 1 s
FAR(False Accept Rate)≤ 0.001 %
FRR (False Rejection Rate)≤ 0.01 %
Fingerprint RecognizerOptical Fingerprint Recognizer Module
External Card ReaderStandard Wiegand26/34
Card Reading DistanceNot Support
KeyboardKeyboard (Back Light)
Reset Key× 1
Wi-FiSupport
Wiegand InterfaceOutput: Wiegand 26/34;Input: Wiegand 26/34
Transmission RateTCP/IP: 10/100Mbps, Self-adaptive;RS485: 19200 bps-N-8-1
USBUSB 2.0; Type A

Magnetic lock supports static linear thrust of 280 kg (617 Lbs)
Power supply can be 12VDC or 24VDC, (default voltage is 12VDC)
Suitable for wooden door, glass door, metal door and fireproof door
LED indicator displays door lock status
Abrasion-proof materials


General
IndicatorGreen: Working Status
Power supply12 VDC, 340 mA × 2
Working temperature-10 °C to 55 °C (14 °F to 131 °F)
Working humidity0 to 95 % (relative humidity)
Dimensions

Lock Body: 238 mm × 45 mm × 25 mm (9.4" × 1.8\" × 1.0\")

Armature Plate: 182 mm × 38 mm × 12.5 mm (7.2 × 1.5\" × 0.5\")"
Weight2.1 kg (4.6 lb)
Material

Shell: hard Anodizing Electroplating Operated

Lock Body: eco-friendly Nickel Electroplating Operated

Armature Plate: eco-friendly Zinc Electroplating Operated
ThrustMax. 280 kg (617 lb)
Door typeSingle leaf, double leaf, wooden door, glass door, metal door, fireproof door

Magnetic Lock/General
Unlock methodCurrent Interruption
Surface temperature≤ Ambient Temperature +20 °C (68 °F)

Value Series Magnetic Lock Bracket


General
Dimensions

L-bracket Dimension (L × W × H): 238 mm × 30 mm × 47 mm (9.4" × 1.2\" × 1.9\");

Z-bracket Dimension (L × W × H): 185 mm × 44 mm × 100 mm (7.3 × 1.7\" × 3.9\")"
Weight0.77 kg (1.7 lb)
MaterialShell: hard anodizing electroplated
Door typeWooden Door, and Metal Door

Bracket of Magnetic Lock/General
Suitable DoorWooden Door, and Metal Door

The Hikvision DS-K7P03 No Touch Exit Button is suitable for all kinds of narrow door frames. Featuring a stainless-steel panel and LED indicator, this product has passed the 1 million times ageing test.

Working temperature -20°C to 50°C
Working humidity 0 to 95% (relative humidity)
Current rating 1 A@30 VDC
Output contact NO/NC/COM contact
Already passed 1 million times ageing test
Stainless steel panel
Suitable for all kinds of narrow door frames
Time delay: 1 to 25 s (adjustable)
LED indicator status: green/red LED indicates working/standby

DS-K7PEB Emergency Break Glass Box isdesigned for exit doors and emergency doors. It ismade of fireproof material and has a sandblastfinish. Has Normally Open (N.O.), Normally Closed(N.C.), and common (COM) contact outputs.

Fireproof Material, Sandblast Finished
Output Contact:N.O/N.C/COM
Suitable for Exit Door, Emergency Door
3A @ 36 VDC Maximum
Optional Accessories: Glass/Transparent Cover Optional Accessories: Glass/Transparent Cover

Wireless internal 25m longrang PIR detector

Detection range: 25 m x 25 m, 20 degrees

RF 868MHz

Offers reliable protection utilizing two-way wireless technology

PIR motion detection

Tamper alarm, intruder alarm

Communicates up to 800 m (in open areas)

DS-PD2-P25-W(868M)

RF 868MHz
Two-way wireless
AES-128 encryption
Detection range: 10m*10m, 90 degrees
2 PIR+Microwave detection
Pet immunity: 24kg
Anti-masking, anti-blocking
Weather proof sealed optics
Communication distance: 800M (in open area)

Detection performance
Detection Range12m
Detection Angle90°
Velocity range0.25m/s ~ 3m/s
Pet Immunity24kg

Software features
Tamper-ProofSupport

Hardware features
IndicatorTri-color LED Indicator

RF transmission
RF Frequency868MHz
RF Range800m (in open area)

Electrical characteristics
Battery type2×3V 4700mAH Lithium Battery packs
Battery life span3 years

General
Operation temperature-25℃ ~ +60℃
Dimension(WxHxD)188mm*77mm*84mm
Weight300g (without bracket)
Application scenarioOutdoor
ColorWhite
Installation height1 ~ 1.5m
Installation methodWall mounted
BracketAdditional Wallbracket, Adaptor and Fixedbracket

Wrist accessory for portable emergency button

Skin-friendly rubber

General

Shell MaterialSkin-friendly rubber

Dimension(WxHxD)38mm×255mm×12mm

Weight15g

Slim design for window frame installation
IP65 weather resistance for outdoor application
Active IR anti-masking
Directional detection support
Multiple enrollment methods and easy installation
Frequency hopping against jamming for reliable transmission

Detection Performance
Detection MethodPassive Infrared;Microwave
Detection Range

Wall mount: 10 m

Ceiling mount: 5 m
Detection Angle5°
Detection Zones32
Detectable Speed0.3～2m/s
SensitivityAuto;Pet
White Light Filter6500lux
Microwave Frequency24GHz(24.15～24.25GHz)
Pet Immunity

Wall mount: 12 kg

Ceiling mount: None
Digital Temperature CompensationSupport
Creep Zone ProtectionSupport
Anti-maskingSupport

Feature
Digital ProcessingSupport
Sealed OpticsSupport
Tamper ProtectionFront;Rear
Environment Temperature IndicatorSupport
Signal Strength IndicatorSupport
Directional DetectionSupport

Interface
Power SwitchPower up enrolling
LED IndicatorGreen (PIR), red (microwave), green+orange (mask), blue (alarm)

Transmission
Transmission TechnologyTri-X Wireless
Transmission MethodTwo-Way RF Wireless
Transmission Frequency868MHz
Transmission SecurityAES-128 Encryption
Transmission Range(Free Space)1.6Km
Frequency HoppingSupport
Enrolling MethodPower up;Remote ID;QR Code

Electrical Characteristics
Standard Battery LifeUp to 5 years (standby time) (The battery working time can be
significantly reduced at low temperatures)
Power SupplyBattery powered
Battery TypeCR123A × 2
Typical Voltage3V

Long range with narrow angle detection
Fully remote configurable through APP
Multiple enrollment method and easy installation design
Easy replaceable battery with PCB protected
Frequency hopping against jamming for reliable transmission

3D optics including creep-zone protection, full coverage without dead angle
24G microwave to prevent wall penetration
Digital temperature compensation
Fully remote configurable through APP
Multiple enrollment method and easy installation design
Easy replaceable battery with PCB protected
Frequency hopping against jamming for reliable transmission

Fully remote configurable through App
Multiple enrollment methods and easy installation design
Effective emergency button
Frequency hopping against jamming for reliable transmission
Feature
Button1
Tamper ProtectionFront;Rear
Environment Temperature IndicatorSupport
Signal Strength IndicatorSupport
Interface
LED IndicatorBlue(Alarm)
Transmission
Transmission TechnologyTri-X Wireless
Transmission MethodTwo-Way RF Wireless
Transmission Frequency868MHz
Transmission SecurityAES-128 Encryption
Transmission Range(Free Space)1.2Km
Frequency HoppingSupport
Enrolling MethodPower up;Remote ID;QR Code

Accidental press protection
Fully remote configurable through APP
IP66 daily environment protection
Frequency hopping against jamming for reliable transmission
Optional lanyard and wristband accessory available
Feature
Button1
Tamper ProtectionNone
Signal Strength IndicatorSupport
Interface
LED IndicatorRed/Green
Transmission
Transmission TechnologyTri-X Wireless
Transmission MethodTwo-Way RF Wireless
Transmission Frequency868MHz
Transmission SecurityAES-128 Encryption
Transmission Range(Free Space)1Km
Frequency HoppingSupport
Enrolling MethodPower up;Remote ID;QR Code

Slim design for an unobtrusive (unnoticeable) installation
Fully remote configurable through APP
Multiple enrollment methods and easy installation design
Frequency hopping against jamming for reliable transmission
Detection Performance
Detection MethodOpening Contact
Detection Gap43 mm Max
Feature
Digital ProcessingSupport
Tamper ProtectionFront;Rear
Environment Temperature IndicatorSupport
Signal Strength IndicatorSupport

Detection Range: 15m/85.9°
Up to 30 kg pet immunity
SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
Fully remote configurable through APP
Multiple enrollment method and easy installation design
Easy replaceable battery with PCB protected
Frequency hopping against jamming for reliable transmission

Detection range: 12m/85.9°
Up to 30 kg pet immunity
SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
Polarizing IR lens design for more uniform night illumination and excellent night shots
Large integrated memory buffer for image storage
Fully remote configurable through APP
Multiple enrollment method and easy installation design
Easy replaceable battery with PCB protected

DS-PDSMK-S-WE AX PRO Wireless Photoelectric Smoke Detector High quality chamber with photoelectric sensor 10 years battery life EN 14604 Certified

Detection Performance
Detection MethodTemperature Sensor
Detection Range
-10°C to 55°C (standalone)
-35°C to 99°C (with included probe)
Feature
Digital ProcessingSupport
Tamper ProtectionFront;Rear
Environment Temperature IndicatorSupport
Signal Strength IndicatorSupport
Interface
LED IndicatorOn screen display
Display
Screen Size2.7 inch
Transmission
Transmission TechnologyTri-X Wireless
Transmission MethodTwo-Way RF Wireless
Transmission Frequency868MHz
Transmission SecurityAES-128 Encryption
Transmission Range(Free Space)1.2Km
