Linkbasic's CAB-P10 is a South African 10 way switched PDU with a moulded direct-attached power cable. It features 10x 16A power sockets enclosed in a 1.5U black Aluminium case.
Cable: Moulded 2m
Size: 1.5U
Material: Aluminium Shell
Voltage: 220V-250V 50Hz-60Hz
Maximum Current: 16A
Mounting: Vertical Mounting in Network Cabinet

Dimensions: 669.2 x 62.2 x 45mm

Linkbasic's UTP-100 is a 4 pair solid copper Category 5e 100m Grey Ethernet Cable supplied in a 100m box.
AWG Rating: 24
Cable Length: 100m
Colour: Grey
Conductor Dimensions: 0.50mm
Construction: UTP - Solid Bare Copper
Cross Filter: None
ESD Drain Wire: None
Number of Pairs: 4
Outer Jacket: PVC

Linkbasic's UTP-6100 is a 4 pair solid copper Category 6 100m Grey Ethernet Cable supplied in a 100m box.
AWG Rating: 23
Cable Length: 100m
Colour: Grey
Conductor Dimensions: 0.565mm
Construction: UTP - Solid Bare Copper
Cross Filter: Yes
ESD Drain Wire: None
Number of Pairs: 4
Outer Jacket: PVC

Linkbasic's UTP-6100A CAT6A 100m Drum of Cable can support data rates of 10Gbps at 100m's. The cable includes a crosstalk filler to improve signal-to-noise ratio and the conductor dimension of 0.575 mm is greater than that of the standard CAT6 cable we stock allowing for faster and more reliable data transmission.
AWG Rating: 23
Cable Length: 100m
Colour: Grey
Conductor Dimensions: 0.575mm
Construction: UTP - Solid Bare Copper
Cross Filter: Yes
ESD Drain Wire: None
Number of Pairs: 4
Outer Jacket: PVC

inkbasic's TC-100 is a 4 pair solid copper, Category 5e UV resistant, outdoor shielded cable offering protection for your network from devastating electrostatic discharge (ESD) attacks. This outdoor FTP cable has been developed to increase power handling performance for extended cable run lengths. It also dramatically improves your Ethernet link-state, speeds, and overall performance.

*Note: This cable is designed for RJ45-FTP and will not work with standard RJ45 connectors.
AWG Rating: 24
Cable Length: 100m
Colour: Black
Conductor Dimensions: 0.510mm
Construction: FTP - Solid Bare Copper
Cross Filter: None
ESD Drain Wire: Yes; Tinned Copper
Number of Pairs: 4
Outer Jacket: UV-PE

Linkbasic's TC-6100 is a 4 pair solid copper, Category 6 UV resistant, outdoor shielded cable offering protection for your network from devastating electrostatic discharge (ESD) attacks. This outdoor FTP cable has been developed to increase power handling performance for extended cable run lengths. It also dramatically improves your Ethernet link-state, speeds, and overall performance.

Note: CAT6 Outdoor cable is only compatible with the RJ45-6FTP connectors.
AWG Rating: 23
Cable Length: 100m
Colour: Black
Conductor Dimensions: 0.573mm
Construction: FTP - Solid Bare Copper
Cross Filter: Yes
ESD Drain Wire: Yes; Tinned Copper
Number of Pairs: 4
Outer Jacket: UV-PE

Linkbasic's TC-FLY10 is a 10m Category 5e UV Shielded outdoor flylead with an integrated ESD drain wire. It will protect your network from the most brutal environments and from devastating electrostatic discharge (ESD) attacks. The outdoor FTP cable has been developed to increase power handling performance for extended cable run lengths. It also dramatically improves your Ethernet link-state, speeds, and overall performance.
AWG Rating: 24
Cable Length: 10m
Colour: Black
Conductor Dimensions: 0.510mm
Construction: FTP - Solid Bare Copper
Cross Filter: None
ESD Drain Wire: Yes; Tinned Copper
Number of Pairs: 4
Outer Jacket: UV-PE

Linkbasic's CAB-12UR is a 12U, 19-Inch desktop open rack with a load capacity of 50kg and is supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: None
Material: Cold Rolled Steel; Powder Coated
Mounting: Wall Mount
Tray Compatibility: None (Direct Mounting Only)

Dimensions: 584 x 503 x 295 mm (H x W x D)

Linkbasic's CAB-12U wall box is manufactured from mild steel and is powder coated with a glass front door.

This 12U wall box is the ideal solution for intermediate sized networks offering versatility and convenience by saving valuable space within any office suite. Once assembled, the case can be stripped down to the basic framework in a matter of seconds via the slide and connect panels.

*Note: Our wall boxes are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: Not Included
Material: Seamless Steel; Powder Coated
Mounting: Fixed Wall-Mount
Shelves: Not Included
Size: 12U 450mm Deep
Tray Compatibility: CAB-T300; CAB-T275
Weight Capacity: 60kg

Dimensions: 635 x 600 x 450mm (H x W x D)
Weight: 28.90kg
Volumetric Weight: 25.50kg

Linkbasic’s CAB-12US is a 12U Swing Frame wall box, manufactured from mild steel and powder coated with a glass front door. The Swing frame assembly allows for easy access to the back of the cabinet with a 90-degree rotation from right to left.


*Note: Our wall boxes are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: Not Included
Material: Cold Rolled Steel; Powder Coated
Mounting: Swing Frame Wall-Mount
Shelves: Not Included
Size: 12U 550mm Deep
Tray Compatibility: CAB-T300; CAB-T275
Weight Capacity: 60kg

Dimensions: 635 x 600 x 550mm (H x W x D)
Weight: 34.50kg
Volumetric Weight: 26.30kg

Linkbasic's TC-FLY15 is a 15m Category 5e UV Shielded outdoor flylead with an integrated ESD drain wire. It will protect your network from the most brutal environments and from devastating electrostatic discharge (ESD) attacks. The outdoor FTP cable has been developed to increase power handling performance for extended cable run lengths. It also dramatically improves your Ethernet link-state, speeds, and overall performance.
AWG Rating: 24
Cable Length: 15m
Colour: Black
Conductor Dimensions: 0.510mm
Construction: FTP - Solid Bare Copper
Cross Filter: None
ESD Drain Wire: Yes; Tinned Copper
Number of Pairs: 4
Outer Jacket: UV-PE

Linkbasic’s CAB-15U6 is a free-standing, 19-Inch, 600mm deep network cabinet. It features a robust design with adjustable feet and heavy-duty castors, manufactured with high-strength steel. Two fans and two shelves are included.

*Note: Free-standing server cabinets are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: 2 Fans (Included)
Material: Cold Rolled Steel; Powder Coated
Mounting: Free Standing (Castors & Feet Included)
Shelves: 2 Flat Shelves (Included)
Size: 15U 600mm Deep
Tray Compatibility: CAB-T300; CAB-T350; CAB-T350S
Weight Capacity: 800kg

Dimensions: 850 x 600 x 600mm (H x W x D)
Weight: 48.99kg

Linkbasic's CAB-15U wall box is manufactured from cool rolled steel and is powder coated with a 5mm thick, tempered smokey grey glass front door.

This Linkbasic 15U wall box is the ideal solution for intermediate sized networks offering versatility and convenience by saving valuable space within any office suite. Once assembled, the case can be stripped down to the basic framework in a matter of seconds via the slide and connect panels.

*Note: Our wall boxes are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: Not Included
Material: Cold Rolled Steel; Powder Coated
Mounting: Fixed Wall-Mount
Shelves: Not Included
Size: 15U 450mm Deep
Tray Compatibility: CAB-T300; CAB-T275
Weight Capacity: 60kg

Dimensions: 789 x 600 x 450mm (H x W x D)
Weight: 33.10kg
Volumetric Weight: 27kg

Linkbasic’s CAB-15U is a 15U Swing Frame wall box, manufactured from cool rolled steel and powder coated with a glass front door. The Swing frame assembly allows easy access to the back of the cabinet with a 90-degree rotation from right to left.

*Note: Our wall boxes are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: Not Included
Material: Cold Rolled Steel; Powder Coated
Mounting: Swing Frame Wall-Mount
Shelves: Not Included
Size: 15US 550mm Deep
Tray Compatibility: CAB-T300; CAB-T275
Weight Capacity: 60kg

Dimensions: 789 x 600 x 550mm (H x W x D)
Weight: 37.80kg
Volumetric Weight: 32.70kg

Linkbasic's CAB-18U6 is a free-standing 19-Inch 600mm deep network cabinet featuring a robust design with adjustable feet and heavy-duty castors. It is manufactured with high-strength steel and includes two fans and two shelves.

*Note: free-standing server cabinets are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: 2 Fans (Included)
Material: Cold Rolled Steel; Powder Coated
Mounting: Free Standing (Castors & Feet Included)
Shelves: 2 Flat Shelves (Included)
Size: 18U 600mm Deep
Tray Compatibility: CAB-T300; CAB-T350; CAB-T350S
Weight Capacity: 800kg

Dimensions: 988 x 600 x 600mm (H x W x D)
Weight: 58.02kg

Linkbasic's FLY-20 is a 20m CAT5e Flylead supplied moulded with a boot to provide additional strain relief. This flylead is rated for 10/100/1000Mbps data transmission speeds with a solid copper design for the best possible performance.
AWG Rating: 24
Cable Length: 20m
Colour: Grey
Conductor Dimensions: 0.510mm
Construction: UTP – Stranded Bare Copper
Cross Filter: None
ESD Drain Wire: None
Number of Pairs: 4
Outer Jacket: PVC

Linkbasic's TC-FLY20 is a 20m Category 5e UV Shielded outdoor flylead with an integrated ESD drain wire. It will protect your network from the most brutal environments and from devastating electrostatic discharge (ESD) attacks. The outdoor FTP cable has been developed to increase power handling performance for extended cable run lengths. It also dramatically improves your Ethernet link-state, speeds, and overall performance.
AWG Rating: 24
Cable Length: 20m
Colour: Black
Conductor Dimensions: 0.510mm
Construction: FTP - Solid Bare Copper
Cross Filter: None
ESD Drain Wire: Yes; Tinned Copper
Number of Pairs: 4
Outer Jacket: UV-PE

Linkbasic's CAB-22U6 is a free-standing 19-Inch 600mm deep network cabinet featuring a robust design with adjustable feet and heavy-duty castors. It is manufactured with high strength steel and includes two fans and two shelves.

*Note: free-standing server cabinets are supplied flat-packed.
Assembly: Supplied Flat Packed
Fans: 2 Fans (Included)
Material: Cold Rolled Steel; Powder Coated
Mounting: Free Standing (Castors & Feet Included)
Shelves: 2 Flat Shelves (Included)
Size: 22U 600mm Deep
Tray Compatibility: CAB-T300; CAB-T350; CAB-T350S
Weight Capacity: 800kg

Dimensions: 1166 x 600 x 600mm (H x W x D)
Weight: 77kg
Volumetric Weight: 62.70kg

Linkbasic's CAB-22UR free-standing open rack with a double frame is mostly used for applications that do not require a high level of protection, since they leave much of the equipment exposed. It allows for easy access and excellent heat dispersion compared to a locked up, fully enclosed cabinet.

Ideal for quick access to network components, communication equipment or other hardware in your workstation with the added benefit of mobility through the available wheels.

*Note: The CAB-22UR comes standard with two shelves.
Assembly: Supplied Flat Packed
Fans: Not Included
Material: Cold Rolled Steel; Powder Coated
Mounting: Free Standing (Castors & Feet Included)
Shelves: 2 Flat Shelves (Included)
Size: 22U 600mm Deep
Tray Compatibility: CAB-T300; CAB-T350
Weight Capacity: 150kg

Dimensions: 1222 x 600 x 600mm (H x W x D)
Weight: 27.50kg
Volumetric Weight: 55.70kg

Linkbasic’s LB-PP24 is a 19 Inch, Rack-Mount, 24 Port Cat5e Patch Panel. This unit is manufactured from black electrostatic powder-coated steel for enhanced corrosion resistance.

*Note: 4 Cage nuts are included with each unit for mounting.
Compatibility: 24AWG
Design: Populated with CAT5e Keystone Jacks
Material: Black Electrostatic Powder-Coated Steel
Size: 1U

Dimensions: 50 x 60 x 510mm
Weight: 70g
