MikroTik' s CRS326 is a Cloud Router Switch featuring 24x Gigabit Ethernet Ports, 2x 10Gbps SFP+ ports and 1x Gigabit Ethernet port for either management or PoE Input. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 10V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 10V-30V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 440 x 144 x 44mm

MikroTik's RB-CRS328 is a Cloud Router Switch featuring 24x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 450W. The 24 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 24x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 44W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3af/at or 26V Passive PoE on Ports 1~24
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 443 x 305 x 44mm

MikroTik's RB-CRS326Q is a Cloud Router Switch featuring 24x 10Gbps SFP+ Ports and 2x 40Gbps QSFP+ ports. The Router has dual power supplies for power redundancy and a full-sized USB port for configuration. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 42W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 650MHz QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 24x 10Gbps ; 2x 40Gbps QSFP
Supported Voltage Range: 100-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None

Dimensions: 443 x 200 x 44mm

MikroTik's RB-CRS304XG is a Cloud Router Switch featuring 4x 10Gbps Ethernet Ports and 1x Gigabit Management Port. This switch includes a convenient DIN rail mount on the side and standard screw attachment points on the back. It also offers 4 different power inputs, 2x DC jacks, a 2-pin terminal, and PoE-input. The switch automatically selects the power source with the highest voltage, ensuring uninterrupted operation.
Ethernet Ports: 4x 10Gbps : 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or DIN Rail Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 48V 0.95A Power Supply
Processor: Dual Core 1200MHz 98DX2528
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 36-57V (PoE) 12-57V (DC Input)
System Memory: 512MB
USB Ports: None
Other: Terminal DC Input

Dimensions: 176 x 128 x 35 mm

MikroTik's RB-CRS305S is a Cloud Router Switch featuring 4x 10Gbps SFP+ Ports, 1x Gigabit Ethernet port for management and dual DC Jacks for power redundancy. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.

*Note: In order to achieve the best compatibility, MikroTik recommends not using grounding when powering this device with 802.3af/at.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Desktop
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 12-57V Passive PoE
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included) (Dual DC input for power redundancy)
Processor: 1 Core 800 MHz 98DX3236
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 12-57V
System Memory: 512MB
USB Ports: None

Dimensions: 141 x 115 x 28mm

MikroTik's RB-CRS354Q is a Cloud Router Switch featuring 48x Gigabit Ethernet ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 48x 10/100/1000 : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: None
Other: None

Dimensions: 297 x 443 x 44mm

MikroTik's RB-CRS354QP is a Cloud Router Switch featuring 48x Gigabit PoE Ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports, 1x Fast Ethernet Management port and a PoE budget of 700W. The 48 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 48x 10/100/1000 : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 85W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3at/af ; 26V or 53V Passive PoE
Power Input: 1x IEC Power Cord (Included)
Processor: QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64 MB
USB Ports: None
Other: None

Dimensions: 443 x 382 x 44mm

MikroTik's RB-CRS106 is a Cloud Router Switch featuring 5x 1.25Gbps SFP ports, 1x 1.25Gbps SFP or PoE Input Combo Port and is powered by RouterOS with a Level 5 license.
Ethernet Ports: 1x 10/100/1000 (Combo Port)
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 70°C
PoE Input: 11V-30V (Passive PoE Combo Port)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 6x 1.25Gbps (1x Combo Port)
Supported Voltage Range: 11V-30V
System Memory: 128MB
USB Ports: None
Other: None

Dimensions: 114 x 137 x 29mm

MikroTik's RB-CRS310S is a Cloud Router Switch featuring 5x 1.25Gbps SFP Ports, 4x 10Gbps SFP+ Ports and 1x Gigabit Ethernet Port which supports PoE Input.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktop & Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 18V-57V or 802.3af/at
Processor: 1 Core 800MHz 98DX226S
Serial Interface: 1x RJ45 Port
SFP Ports: 5x 1.25Gbps ; 4x 10Gbps
Supported Voltage Range: 18V-57V
System Memory: 256MB
USB Ports: None
Other: None

Dimensions: 200 x 166 x 45 mm

MikroTik's RB-CRS312 is a Cloud Router Switch featuring 8x 10Gbps Ethernet Ports, 4 combo ports for either 10Gbps SFP+ or 10Gbps Ethernet and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 12x 10Gbps (4 Combo Ports) : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -30°C to 70°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 1 Core 650MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps (Combo Ports)
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None

MikroTik's RB-CRS310 Cloud Router Switch features a Marvell 98DX226S switch-chip, integrated dual-core ARM CPU, 8x 2.5Gbps Ethernet Ports and 2x 10Gbps SFP+ Ports in a Rack-Mount enclosure.
Ethernet Ports: 8x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature:-40°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 24V 1.5A Power Supply (Included)
Processor: 2 Core 800MHz 98DX226S ARM 32bit
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 18-57V
System Memory: 256MB
USB Ports: 1x USB Port

Dimensions: 200 x 206 x 44 mm

MikroTik's RB-CRS1128P is a Cloud Router Switch featuring 8x Gigabit PoE ports and 4x 1.25Gbps SFP ports. The 8 PoE ports support both passive PoE (with the included Power Supply) and 802.3af/at when powered by a 48-57V power supply. The unit is powered by RouterOS with a Level 5 License.

Note: Both 24V and 52V PSU's can be used simultaneously to make use of both voltages for POE devices.
Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop & Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 18V-28V (Passive PoE) or 48V-57V (802.3af/at)
Power Input: 28V 3.4A Power Supply (Included) or 48-57V (Not Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 18V-28V or 48V-57V
System Memory: 128MB
USB Ports: None
Other: None

Dimensions: 200 x 143 x 44mm

Mikrotik's RB-CRS309S is a Cloud Router Switch featuring 8x 10Gbps SFP+ ports and 1x Gigabit Ethernet port for either management or PoE Input. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 17W
Mounting: Desktop & Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18V-57V (Passive PoE; 802.3af/at)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: 2 Core 800MHz 98DX8208
Serial Interface: 1x RS232 Port
SFP Ports: 8x 10Gbps
Supported Voltage Range: 12V-57V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 272 x 191 x 44mm

MikroTik Cloud Router Switch (CRS125-24G-1S-RM)

Cloud Router Switch is our new Smart Switch series. It is a fully functional Layer 3 switch, and is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special switch menu, but ports can be removed from the switch configuration, and used for routing purposes where required.

The perfect SOHO gateway router, switch, all in one box:

Ethernet, Fiber, or 4G (with optional USB modem) gateway connection to Internet
RouterOS gateway/firewall/VPN router with passive cooling
up to twenty-five gigabit switch ports (1xSFP and 24xRJ45)

MikroTik’s RB-CUBE60P is a 60GHz 802.11ay CPE featuring automatic 5.8GHz 802.11ac failover, 1x Gigabit Ethernet and a durable, unobtrusive enclosure. Establish an ultra-fast, Point-to-Point connection for distances up to 2.4km with Channel 5 enabled.
Antenna Gain: 5.8GHz: 11.5dBi : 60GHz: N/A Recommended for up to 2.4km
Beam-width: 5.8GHz: 35° : 60GHz: 11°
Data Rate: 60GHz: up to 1Gbps+ : 5.8GHz: 433Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Pole-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 18V-57V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: None

Dimensions: 115 x 95 x 82mm

MikroTik's RB-CUBE60PS is an outdoor, 802.11ay 60GHz 60° Integrated Sector with automatic 5.8GHz 802.11ac failover, 1x Gigabit Ethernet and a durable, unobtrusive enclosure. Pair the unit with up to x8 60GHz CPE's to create a Point-To-Multi-Point Link for distances up to 800m.
Antenna Gain: 5.8GHz: 11.5dBi : 60GHz: N/A Recommended for up to 800m
Beam-width: 5.8GHz: 35° : 60GHz: 60°
Data Rate: 60GHz: up to 1Gbps+ : 5.8GHz: 433Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 13W
Mounting: Pole-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 18V-57V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: None

Dimensions: 115 x 211 x 90 mm

MikroTik's ANT-O25 is a dual band, outdoor, RP SMA whip antenna featuring 3.3dBi gain on 2.4GHz and 5.5 - 7.1dBi on 5.8GHz. Pair this antenna with any dual band access point with RP SMA Female connectors to create a dual band outdoor access point.
Antenna Gain: 2.4GHz 3.3dBi ; 5.8GHz 5.5-7dBi
Connectors: RP SMA Male

You can’t buy safety, but you can buy MikroTik devices to keep your setup safe. Take a look at the GESP product line. It consists of a new revision of the classic MikroTik GESP surge protector and a brand new device – the GESP+POE-IN, a passive PoE injector with surge protection. Together these two devices offer maximum security and peace of mind.


Here’s what a typical use-case would be like. You have a mast with some antennas. And some switches on the ground. Put the GESP surge protector up there. It comes sealed inside a new and improved IP67 weatherproof enclosure. Your antennas are now safe during a lightning storm. Now add the GESP+POE-IN injector below the mast - to protect the switches and to power the antennas.


Don’t forget about the grounding wire! Secure it to the rackmount, mast, or any other structure that is connected to the ground. For maximum protection, you should use a surge protector on both ends of long cables.


These small devices can make all the difference when it comes to lightning strikes or static build-up.


The GESP units can usually absorb multiple impacts, but make sure to check their condition after each surge. For attachment of GESP units, we recommend using PVC zip ties. Just don’t make it too tight. You know what they say – hope for the best, prepare for the worst. This small investment can save lots of time and money, so why risk it? Grab a GESP & GESP+POE-IN and put your mind at ease!

MikroTik's RB-GPEN21 is a smart media converter with PoE pass-through running SwOS. It provides a range of useful software features such as Interface management and monitoring, GPEN link fault detection, VLAN support, SNMP reporting and Basic traffic shaping. This unit has 2 Gigabit Ethernet ports as well as an SFP port for fibre connectivity. The RB-GPEN21 can be used either to power a fibre module or to provide PoE to power an Ethernet uplink using RB-GPER.

*Note: Power supply not included.

Easy Printable Label
For your convenience, we have created an editable label template available for download under this product's 'More Information' tab. Once downloaded to your computer, the template allows you to input your company information and logo. Label product: Redfern 66 x 20.69 mm (39 UP).
SKU RB-GPEN21
Manufacturer MikroTik
Manufacturer Product Code GPEN21
GPEN Concept
Label - Redfern 39UP
Specifications Ethernet Ports: 2x 10/100/1000
Hardware Button: Mode
Mounting: Wall-Mount
Operating System: SwOS
Operating Temperature: -20°C to 70°C
PoE Input: 802.3af/at
PoE Output: 12V-57V Passive PoE
Power Input: Passive PoE
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 12V-57V

Dimensions: 92 x 104 x 24mm

MikroTik GPeR

The GPeR unit allows to extend Ethernet cable by additional hop (< 100 - 150 m to regular network devices, and up to 210 m to another GPeR unit) up to 1,500 m.

Handy for highrise buildings, multi-apartment buildings, with many floors and sections, where very long Ethernet cables might be a problem.

Maximium allowed length of CAT6 Ethernet cable between GPeR and power source/router is up to 100 m (depending on cable quality, high quality - up to 150 m).

Maximium allowed distance of CAT6 Ethernet cable between two GPeR devices is up to 210 m (depending on cable quality).

Use case 1: Extension of Ethernet link to up to 1,5 km if one side have PoE source (up to 3 km both sides of the link have PoE sources).

Use case 2: Home user connects his WiFi AP to GPEN11, which then outputs PoE (Power over Ethernet), Ethernet is extended with GPeR units then on the roof you have a netPower series switch (coming later this year), which takes power from all the apartments (from GPEN11), after that the switch is connected to the uplink connection, for example with our 60 GHz series of device.
