MikroTik's RB-HAPAX3 WiFi 6 router features a quad-core ARM 1.8GHz CPU, 4x Gigabit Ethernet Ports and 1x 2.5Gbps Ethernet Port and an aggregate data rate of up to 1800Mbps. It also features 1x USB 3.0 port for external storage or 4G/LTE modem as well as PoE input and output.

The universal case design allows the unit to be positioned either horizontally or vertically.
Antenna Gain: 2.4GHz: 3.3dBi 5.8GHz: 5.5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps 5.8GHz: 1200Mbps
Ethernet Ports: 4x 10/100/1000 ; 1x 2.5Gbps
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop
Operating System: RouterOS v7 (Level 6 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18V-28V (Passive PoE)
PoE Output: Passive PoE on Port 1
Power Input: 24V 1.5A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12V-28V
USB Ports: 1x USB 3.0
Other: None

MikroTik's RB-HEX is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a full-size USB port, affordable, small and easy to use. It features a very powerful dual-core 880MHz CPU and 256MB RAM, capable of all the advanced configurations supported by RouterOS.

IPsec Hardware encryption (~470Mbps) and dude server package is also supported. Its microSD slot provides improved r/w speed for database storage on a microSD card.
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 5W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 8V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 0.38A Power Supply (Included)
Processor: 2 Core 880MHz , MT7621A
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 8V-30V
System Memory: 256MB
USB Ports: 1x USB 2.0
Other: 1x microSD Memory Card Slot

Dimensions: 113 x 89 x 28mm

MikroTik's RB-HEXLITE is a small five port ethernet router in a practical plastic case. It is well priced and the perfect choice when it comes to managing your wired home network.

No more compromise between price and features - RB-HEXLITE has both. With its compact design and clean looks, it will fit perfectly into any SOHO environment.
Ethernet Ports: 5x 10/100
Hardware Button: Reset
Max. Power Consumption: 2W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 6V-30V (Passive PoE)
PoE Output: None
Power Input: 12V 0.5A Power Supply (Included)
Processor: 1 Core 850MHz, QCA9533
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 6V-30V
System Memory: 64MB
USB Ports: None
Other: None

Dimensions: 113 x 89 x 28mm

MikroTik's RB-HEXPOE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and an SFP port for adding optical fibre connectivity. Ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. This powerful 800MHz CPU is a cost-effective, small, easy to use and capable of all the advanced configurations supported by RouterOS. The maximum current is 1A per port and the Ethernet ports are shielded.
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 12V-57V (Passive PoE, 802.3af/at)
PoE Output: 12V-57V Passive PoE, 802.3af/at on Ports 2 to 5
Power Input: 24V 2.5A Power Supply (Included)
Processor: 1 Core 800MHz, QCA9557
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 12V-57V
System Memory: 128 MB
USB Ports: 1x USB 2.0
Other: None

Dimensions: 114 x 137 x 29mm

MikroTik's RB-HEXPOEL is a compact 5 port router featuring 5x shielded Fast Ethernet ports and 1x USB port. It accepts passive PoE input on Port 1 and Ports 2-5 can power other PoE-capable devices with the same voltage as applied to the unit with a maximum of 1A per port.
Ethernet Ports: 5x 10/100
Hardware Button: Reset
Max. Power Consumption: 3W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 6-30V (Passive PoE)
PoE Output: 6-30V (Passive PoE) on Ports 2 to 5
Power Input: 24V 2.5A Power Supply (Included)
Processor: 1 Core 650MHz, QCA9531
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 6-30V
System Memory: 64 MB
USB Ports: 1x USB 2.0
Other: None

Dimensions: 113 x 89 x 28mm

The affordable, reliable router you know and trust is now stronger than ever. With the latest refresh, the MikroTik hEX delivers twice the performance for the same great price. Whether you’re looking for a rock-solid solution for your home or small office, hEX ensures seamless and stable connectivity with a powerful upgrade: we’ve increased the RAM from 256 MB to 512 MB, and replaced the CPU with a modern ARM64-bit dual-core workhorse!


Depending on your configuration, the performance increase can reach 100-134%! With 5x Gigabit Ethernet ports, hEX is the most cost-effective way to interconnect your main home or office devices. And you can use the full-sized USB port to add extra storage to stream high-quality media across devices!

MikroTik's RB-HEXS is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. Compared to the RB-HEX, the RB-HEXS also features an SFP port and PoE output on the last port.

It is small and easy to use but comes with a very powerful dual-core 880 MHz CPU and 256 MB RAM, capable of all the advanced configurations that RouterOS supports. The device has a USB 2.0, PoE output on Ethernet port 5 and a 1.25G SFP cage.
thernet Ports: 5x 10/100/1000
Hardware Button: Rest
Max. Power Consumption: 6W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 12V-57V (Passive PoE, 802.3af/at)
PoE Output: 12V-57V Passive PoE, 802.3af/at on Port 5
Power Input: 24V 1.2A Power Supply (Included)
Processor: 2 Core 880MHz, MT7621A
Serial Interface: None
SFP Ports: 1x 1.25Mbps
Supported Voltage Range: 12V-57V
System Memory: 256MB
USB Ports: 1x USB 2.0
Other: 1x microSD Memory Card Slot

Dimensions: 113 x 89 x 28mm

MikroTik's ANT-MLTE is a 5dBi LTE Omni Antenna operating on the 699 - 2690 MHz frequency range. The device housing is a flat design for easy mounting, but the antenna itself is omni directional and does not have to be accurately pointed, allowing for simple installation.
Antenna Gain: 5dBi
Beam-width: 360°
Connector: 2x SMA Female
Frequency Range: 699 to 2690MHz
Polarization: Vertical & Horizontal

Dimensions: 129 x 129 x 34mm

MikroTik's ANT-D530PA is a 5GHz 30dBi dish antenna and precision alignment mount built to accommodate the BaseBox series of products. It can also be used with any pole-mounted, 5GHz wireless device due to the adequate length of the included FlexGuide cable.

*Note: Radio not included
Antenna Gain: 30dBi
Beam-width: +/-2.5 deg
Connector: 2x RP SMA Female
Frequency Range: 4.7GHz-5.875GHz
Polarization: Vertical & Horizontal
Wind Loading: 181.4kg @ 200km/hr

Dimensions: Ø 700 x 450mm

PLEASE TAKE NOTE:
This product is the MikroTik Dish ONLY. Electronic devices/CPE’s such as the MikroTik BaseBox5 or Ubiquiti RocketM5 are sold separately and not included. Pictures for the mANT30 dish are for illustration purposes only and shows the CPE mounting position for items such as the BaseBox5.

MikroTik's RB-MANTBOX15AX is a dual band, WiFi 6 base station with an integrated sector antenna. The unit features a Gigabit Ethernet Port as well as a 2.5Gbps SFP slot and an aggregate data rate of up to 2974Mbps. On 2.4GHz the antenna offers 12dBi at 90°, and on 5.8GHz 15dBi at 60° coverage.

*Note: Maximum distance must be configured for client connections over 2km.
Antenna Gain: 2.4GHz: 12dBi ; 5.8GHz: 15dBi
Beam-width: 2.4GHz: 90°; 5.8GHz: 60°
Data Rate: 2.4GHz 574Mbps ; 5.8GHz 2400Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Pole-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18-28 (Passive PoE)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 12-28V
USB Ports: 1x USB 2.0
Other: 1x 2.5Gbps SFP

Dimensions: 349 x 140 x 82 mm

MikroTik's RB-MAP is a tiny sized, 2.4GHz wireless Access Point with full RouterOS capabilities. It is portable and accepts power from a wide variety of sources - USB, Passive or power jack. It also functions as a PoE injector - the second Ethernet port can provide up to 500mA of power to another device, for example, you can connect an SXT CPE device to it.
Antenna Gain: 1.2dBi
Beam-width: 360°
Data Rate: 2.4GHz 300Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset
Max. Power Consumption: 5W
Mounting: Desktop
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -20°C to 70°C
PoE Input: 12V-57V (Passive PoE, 802.3af/at) Or 5V 1A USB Power
PoE Output: 12V-57V PoE Pass-Through on Port 2
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 5V or 12V-57V
USB Ports: 1x MicroUSB
Other: None

Dimensions: 68 x 68 x 19mm

With netPower Lite 7R switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.

With this switch you won’t have to worry about power issues, as there are many options. netPower Lite 7R has 7 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 8 can power other PoE capable devices with the same voltage as applied to the unit. There is also a DC jack and a 2-pin terminal for alternative powering.

The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower Lite 7R has a non-blocking throughput of 28 Gbps, switching capacity of 56 Gbps and forwarding rate of 41.7 Mpps.


The power supply is NOT included with the product- must be purchased separately. Read more information about GPEN concept.

MikroTik's RB-NETPOWER16P is an outdoor 18 port switch. It has 16x Gigabit Ethernet Ports, with PoE-out, and 2x SFP+ ports for 10G fibre uplinks. The sturdy and compact design allows this switch to be mounted in various environments, from damp attics and shafts to towers, masts and poles with the included hose clamps.

This product does not support voltage conversion but rather makes use of separate 24V and 48V input power supplies. The netPower will automatically select the correct PoE standard and voltage based on the devices connected to each port if both voltages are being used simultaneously. This can also be configured manually on the product interface.

*Power supply is NOT included with the product. You are welcome to use your preferred power option, like battery pack etc. Compatible also with MikroTik power supplies 24HPOW, 48POW and 48V2A96W

thernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16W
Mounting: Pole-Mount
Operating System: RouterOS Level 5 License
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: 24v Passive PoE or 802.3af/at
Power Input: 2x DC Jacks (18V-30V or 48V-57V)
Processor: 98DX226S
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 18V-30V or 48V-57V
System Memory: 16MB
USB Ports: None

Dimensions: 303 x 212 x 78mm

MikroTik quickMOUNT-X – additional axis for pole-mounting SXTsq devices


The new QM-X adapter enables vertical and horizontal adjustment on the pole. It is lightweight, easy to use, extremely durable and without any small parts that might break. Pick it up today for the price of a milkshake and enjoy simple positioning of your SXTsq devices like never before!


Specifications

Dimensions - 60 x 56 x 35 mm

Tube diameter - 30 mm

Max tube diameter to which mount can be attached - 60 mm

Maximum antenna weight - 2 kg

Compatible devices - SXTsq series, DISC 5

Material - Glass fibre reinforced nylon

MikroTik's RB-WAPLORA8 is an out-of-the-box LoRaWAN gateway solution. This kit contains a pre-installed UDP packet forwarder to any public or private LoRa servers. It is an outdoor weatherproof wireless access point with 2.4GHz WLAN interface and Ethernet port that could be used as a back-end.
Antenna Gain: Lora: 2dBi Wireless: 2dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Desktop; Ceiling; Pole & Wall-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 9V-30V Passive PoE
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: 1 Mini SIM
Supported Voltage Range: 9V-30V
USB Ports: None

Dimensions: 185 x 85 x 30mm

MikroTik's RB-WAPLTE is a small weatherproof wireless access point with a built-in LTE4 modem that supports 2G, 3G and 4G (LTE) connectivity. Connect to the wAP’s built-in 802.11b/g/n wireless and access the LTE network from your phone or any other wireless device. The RB-WAPLTE also has one 10/100 Ethernet LAN port for your wired devices.

LTE cards are connected to two internal antennas with u.FL connectors, making it possible to unplug the connectors and add your own external LTE antenna for larger coverage. The RB-WAPLTE has several powering options - 9-30v PoE-in by Ethernet port, DC jack and Automotive connector for the car, bus or train. It includes LTE modem that supports International LTE bands 1,2,3,7,8,20,28,38 and 40.
Antenna Gain: LTE: 2 - 4.5dBi (with uFL connector) Wireless: 2dBi
Beam-width: 360°
Data Rate: LTE: 150Mbps Downlink; 50Mbps Uplink ; Wireless: 2.4GHz 300Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktop; Ceiling; Pole & Wall-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to +60°C
PoE Input: 9 – 30V (Passive PoE)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: 1 (Mini SIM)
Supported Voltage Range: 9V-30V
USB Ports: None

Dimensions: 185 x 85 x 30 mm

MikroTik's RB-WAPAC features a white outdoor weatherproof enclosure, 2x Gigabit Ethernet Ports, 802.11ac (WiFi 5) and a quad-core CPU. With multiple mounting options the RB-WAPAC can be wall, ceiling or pole mounted. It allows for an Ethernet cable to be run directly from the back of the case and is secured with an anti-vandal screw for added security.
Antenna Gain: 2.4GHz: 2.5dBi ; 5.8GHz: 2.5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop, Ceiling, Pole & Wall-Mount
Operating System: RouterOS (Level 4 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 18-57V Passive PoE ; 802.3af/at
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 10-57V
USB Ports: None

Dimensions: 185 x 85 x 30 mm

MikroTik's RB-WAPLTE6AC is a small weatherproof, dual-band 802.11ac Access Point. LTE6 also enables carrier aggregation and allows the device to use multiple bands simultaneously, which is a great advantage when there are many LTE users in the area.
Antenna Gain: LTE: 4dBi ; Wireless: 2.5dBi
Beam-width: 360°
Data Rate: LTE: 300Mbps Downlink; 50Mbps Uplink ; Wireless: 2.4GHz: 300Mbps 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16W
Mounting: Pole-Mount
Operating System: RouterOS (Level 4 License)
Operating Temperature: -30°C to 60°C
PoE Input: 18V-57V (Passive PoE; 802.3af/at)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Serial Interface: None
SIM Slots: 1 (Micro SIM)
Supported Voltage Range: 10V-57V
USB Ports: None

Dimensions: 185 x 85 x 30mm

Multifunctional RJ45 Crimping Tool with Built-in Wire Tester

Designed for versatility, this tool effortlessly handles RJ45, RJ11, and RJ12 connectors, making it an essential addition for both professionals and DIY enthusiasts.

Key Features:

Comprehensive Functionality: This crimping tool seamlessly combines crimping, shearing, stripping, and measuring functions, streamlining your workflow and improving efficiency.
Built-in Wire Tester: The crimper includes a convenient, removable wire tester located on the handle, ensuring that you can quickly verify connections without needing additional tools.
Durable Construction: Crafted from high hardness precision materials, this lightweight tool is both durable and portable, promising a long service life while being easy to carry.
Precision Alignment: The tool’s design guarantees that the external dimensions of crimped wires align perfectly with the crystal head, reducing misalignment and ensuring a secure connection for twisted pairs.
Smooth Cutting and Stripping: Equipped with high-quality blades, our crimper provides a clean, burr-free cut. The blade spacing is optimized for stripping rubber from twisted pairs without damaging the network cable.
Efficient Ratchet Mechanism: The built-in ratchet structure enhances crimping efficiency, allowing you to save time and effort during your projects.
Comfortable Grip: The handles are made from a special soft rubber material, offering a non-slip grip for maximum comfort during prolonged use.

Upgrade your toolkit with the Multifunctional RJ45 Network Cable Crimper and simplify your networking tasks. Whether you're setting up a new network or maintaining existing connections, this tool is designed to meet all your crimping needs with precision and reliability.

**Please note that the wire tester requires 3x LR44 batteries which are not included.
