Ubiquiti's AIR-S215 is a 2GHz 15dBi, 120° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Antenna Gain: 15dBi
Beam-width: 120°
Connector: 2x RP SMA Female
Frequency Range: 2.3GHz – 2.7GHz
Polarization: Vertical & Horizontal
Wind Loading: 169N @ 200km/h

Dimensions: 700 x 145 x 93mm
Weight: 4.0kg

Ubiquiti's AIR-O510 is a 5GHz 10dBi, 360° airMAX Omni antenna designed to seamlessly integrate with Ubiquiti Radio's.

*Note: Radio not included.
Antenna Gain: 10dBi
Beam-width: 360°
Connector: 2x RP SMA Female
Frequency Range: 5.45GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 71.17N @ 200km/h

Dimensions: 582 x 90 x 65mm
Weight: 0.68kg

Ubiquiti's AIR-O513 is a 5GHz 13dBi, 360° airMAX Omni antenna designed to seamlessly integrate with Ubiquiti Radio's.

*Note: Radio not included.
Antenna Gain: 13dBi
Beam-width: 360°
Connector: 2x RP SMA Female
Frequency Range: 5.45GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 84.52N @ 200km/h

Dimensions: 799 x 90 x 65mm
Weight: 0.82kg

Ubiquiti's AIR-S517 is a 5GHz 17dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.

Antenna Gain: 17dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 4.90GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 41.7N @ 200km/h

Dimensions: 367 x 63 x 41mm
Weight: 1.1kg

Ubiquiti's AIR-S519 is a 5GHz 19dBi, 120° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.
Antenna Gain: 19dBi
Beam-width: 120°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 137.9N @ 200km/h

Dimensions: 700 x 135 x 73mm
Weight: 5.9kg

Ubiquiti's AIR-S520 is a 5GHz 20dBi, 90° airMAX sector antenna designed to seamlessly integrate with Ubiquiti Radios. The antenna features excellent cross-polarization isolation for improved noise resistance and superior beam performance.

*Note: Radio not included.
Antenna Gain: 20dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Frequency Range: 5.15GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 182N @ 200km/h

Dimensions: 700 x 135 x 70mm
Weight: 5.9kg

Ubiquiti's AIR-D530 is a 5GHz 30dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D530 features a robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 30dBi
Beam-width: 5°
Connector: 2x RP SMA Female
Frequency Range: 4.9GHz - 5.8GHz
Polarization: Vertical & Horizontal
Wind Loading: 787N @ 200km/h

Dimensions: Ø 650 x 304mm
Weight: 9.8kg

Ubiquiti's UISP-DISH is a 5GHz 30dBi dish antenna designed to seamlessly integrate with Ubiquiti radios. The antenna provides extended coverage by utilising a wide frequency range. The unit comes with a precision mounting bracket for easy installation and alignment.

*Note: Radio not Included.
Antenna Gain: 30dBi
Beam-width: 5 to 6° (3 dB) / 6.5 to 8° (6 dB)
Connector: WaveGuide Adapter (Included)
Frequency Range: 5.15 - 6.875GHz
Polarization: Vertical & Horizontal
Wind Loading: 860 N at 200 km/h

Dimensions: Ø 650 x 200 mm
Weight: 7.64Kg

Ubiquiti's AIR-D530LW is a 5GHz 30dBi lightweight dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

*Note: Radio not included.
Antenna Gain: 30dBi
Beam-width: 5.8°
Connector: 2x RP SMA Female
Frequency Range: 5.1GHz - 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 790N @ 200km/h

Dimensions: Ø 650 x 386mm
Weight: 7.4kg

Ubiquiti's AIR-D534 is a 5GHz 34dBi dish antenna designed to seamlessly integrate with the Ubiquiti Radios.

Incorporating a dish reflector design for excellent beam directivity, the AIR-D534 features robust mechanical design using industrial-strength hardware for outdoor applications.

*Note: Radio not included.

Antenna Gain: 34dBi
Beam-width: 3°
Connector: 2x RP SMA Female
Frequency Range: 4.9 – 5.9GHz
Polarization: Vertical & Horizontal
Wind Loading: 1;779N @ 200km/h

Dimensions: Ø 1050 x 421mm
Weight: 13.5kg

Ubiquiti's AIR-S521AC is a 5GHz 21dBi, 60° airMAX ac, sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.
Antenna Gain: 21dBi
Beam-width: 60°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 391N @ 200km/h

Dimensions: 750 x 173 x 78mm
Weight: 4.8Kg

Ubiquiti's AIR-S522AC is a 5GHz 22dBi, 45° airMAX AC sector antenna designed to seamlessly integrate with Ubiquiti's AC Rockets providing noise isolation and improved beam performance in co-location deployments.

*Note: Radio not included.

Antenna Gain: 22dBi
Beam-width: 45°
Connector: 2x RP SMA Female
Frequency Range: 5.10GHz – 5.85GHz
Polarization: Vertical & Horizontal
Wind Loading: 347N @ 200km/h

Dimensions: 750 x 215 x 94mm
Weight: 6kg

Ubiquiti's ISO-514AC is a shielded airMAX ac 5GHz radio with a 14dBi, 45° symmetrical horn antenna. It can be used as a PtMP (point to multipoint) access point in high-interference environments and is easily co-located due to its small size. It can also be used as a short-range CPE (client premises equipment). The antenna can be interchanged with any of the other horn antennas from Ubiquiti's range (sold separately). The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

The IsoStation 5AC uses horn antenna sectors designed for increased co-location performance without sacrificing gain. Providing high throughput and an innovative form factor, the IsoStation 5AC is versatile and cost-effective to deploy.

The IsoStation 5AC comes with a 45° isolation antenna.

Antenna Gain: 14dBi
Beam-width: 45°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20-26V
USB Ports: None

Dimensions: 174 x 174 x 150mm
Weight: 725.7g

Ubiquiti's LAP-516AC is an airMAX ac 5GHz radio with 16dBi, 120° sector antenna. It is designed as a lightweight, cost-effective PtMP (point to multipoint) access point solution. The bracket requires minimal tools for adjustment to simplify installation.
Antenna Gain: 16dBi
Beam-width: 120°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V, 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20-26V
USB Ports: None

Dimensions: 452.3 x 78.7 x 54.4mm
Weight: 420g

Ubiquiti's LAP-517AC is an airMAX ac 5GHz radio with 17dBi, 90° sector antenna with GPS. It is designed as a lightweight, cost-effective PtMP (point to multipoint) access point solution. The GPS radio is used in co-location environments to assist with mitigating interference. The bracket requires minimal tools for adjustment to simplify installation. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 17dBi
Beam-width: 90°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7.1W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.3A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20-26V
USB Ports: None

Dimensions: 360.98 x 124.57 x 71.28mm
Weight: 752g

Ubiquiti's LBE-523ACG2 is an airMAX AC 5GHz radio with a 23dBi antenna. It is designed as a lightweight, cost-effective, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 23dBi
Beam-width: 15°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.3A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 358 x 271.95 x 272.5mm
Weight: 980g

Ubiquiti's LBE-526ACLR is an airMAX AC 5GHz radio with a 26dBi antenna. It is designed as a lightweight, cost-effective, CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 26dBi
Beam-width: 12°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.3A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 512.5 x 385.75 x 258.3mm
Weight: 1.735g

Ubiquiti's LBE-529ACXR is an airMAX AC 5GHz radio with a 29dBi antenna. It is designed as a lightweight, long-range, CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 29dBi
Beam-width: 7.5°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22-26V
USB Ports: None

Dimensions: 747 x 525 x 347 mm
Weight: 3.2 kg

Ubiquiti's LBE-523 is an airMAX M series 5GHz radio with a 23dBi antenna. It is designed as a lightweight, cost-effective, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. It can be managed via the UISP network management platform.
Antenna Gain: 23dBi
Beam-width: 15°
Data Rate: 150Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 4W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V; 0.2A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 362 x 267 x 184mm
Weight: 750g

Ubiquiti's LOCO-5ACL is an airMAX AC 5GHz radio with a 13dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) solution or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: The LOCO-5ACL does not ship with a PoE adapter; we recommend powering the unit with our UPOE-24G12W
Antenna Gain: 13dBi
Beam-width: 45°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V Passive PoE
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 179 x 77.5 x 59.1mm
Weight: 180g
