Ubiquiti's UDM-MAX is an all-in-one enterprise-grade UniFi OS Console. It supports the full UniFi application suite and features an advanced security gateway with dual-WAN ports (2.5Gbps Ethernet & SFP+), 8 port Gigabit switch, a 10G SFP+ LAN Port and 2x 3.5" HDD Bays for NVR Storage (2.5" HDD also supported). It features a 1.3" LCM (Liquid Crystal Monitor) colour touchscreen to display key system and connection information.

*Note: Hard drives not included.
Ethernet Ports: 8x 10/100/1000 (LAN) ; 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included); 1x RPS DC Input
Processor: 2.0GHz Arm Cortex-A57 Quad-Core
Serial Interface: None
SFP Ports: 2x 10Gbps (1xLAN 1xWAN)
Supported Voltage Range: 100V-240V
System Memory: 8 GB DDR4
USB Ports: None

Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 4.7kg

Ubiquiti's UDM-MAX is an all-in-one enterprise-grade UniFi OS Console. It supports the full UniFi application suite and features an advanced security gateway with dual-WAN ports (2.5Gbps Ethernet & SFP+), 8 port Gigabit switch, a 10G SFP+ LAN Port and 2x 3.5" HDD Bays for NVR Storage (2.5" HDD also supported). It features a 1.3" LCM (Liquid Crystal Monitor) colour touchscreen to display key system and connection information.

*Note: Hard drives not included.

Ethernet Ports: 8x 10/100/1000 (LAN) ; 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included); 1x RPS DC Input
Processor: 2.0GHz Arm Cortex-A57 Quad-Core
Serial Interface: None
SFP Ports: 2x 10Gbps (1xLAN 1xWAN)
Supported Voltage Range: 100V-240V
System Memory: 8 GB DDR4
USB Ports: None

Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 4.7kg

Ubiquiti's UDM-SE is an all-in-one enterprise-grade UniFi OS Console. It is designed to host the full UniFi application suite. It comes with an advanced security gateway feature set and a built-in 8-Port Switch with 6 PoE and 2 PoE+ ports. It also features Dual WAN Ports (one 10G SFP+ and one 2.5Gbps RJ45), a 10G SFP+ LAN Port and a 3.5" HDD Bay for NVR Storage (2.5" HDD also supported). It features a 1.3" LCM (Liquid Crystal Monitor) colour touchscreen to display key system and connection information. PoE budget on the unit is 190W.

*Note: Hard drive not included.

Ethernet Ports: 1x 10/100/1000/2500 (WAN); 8x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: 6x 802.3af ; 2x 802.3at
Power Input: 1x IEC Power Cord (Included); 1x RPS DC Input
Processor: Quad-Core ARM® Cortex®-A57 at 1.7 GHz
Serial Interface: None
SFP Ports: 2x 10Gbps (1xLAN; 1xWAN)
Supported Voltage Range: 100V-240V ; 44-57V (802.3af) ; 50-57V (802.3at)
System Memory: 4 GB DDR4
USB Ports: None

Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 4.95kg

Ubiquiti UDW is a Wall-mountable UniFi Gateway which features 17x Gigabit Ethernet ports with 12x PoE Ports, 1x 2.5Gbps Ethernet Port, 2xSFP+ 10Gbps Ports as well as a built-in WiFi 6 access point and network video recorder. The WiFi 6 delivers an aggregate data rate of up to 2.7Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MIMO) bands. It also features a 4.7" touchscreen for management, 128GB SSD & pre-installed 512GB microSD card and can be configured and managed with the UniFi Network Application.
Antenna Gain: 2.4GHz: 5.9dBi; 5.8GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 2400Mbps
Ethernet Ports: 17x 10/100/1000 ; 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 532W
Mounting: Wall Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: 12x PoE Ports (4x 802.3af ; 4x 802.3at ; 4x 802.3bt)
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 1x 10Gbps LAN; 1x 10Gbps WAN
SIM Slots: None
Supported Voltage Range: 100-240V
USB Ports: None
Other: 1x Micro SD memory card

Dimensions: 549 x 342 x 62 mm
Weight: 8.6kg

Ubiquiti's EFG is a 25Gbps, Multi-WAN Enterprise Cloud Gateway featuring 2x SFP28 25Gbps ports, 2x SFP+ 10Gbps ports and 2x 2.5Gbps Ethernet ports. It is designed for high availability and equipped with 2x hot-swap power supplies for redundancy. It features advanced routing, security, and VPN functionality with further enterprise features such as Virtual Router Redundancy, SSL/TLS inspection and anti-malware with in-line sandboxing (coming soon). A UniFi OS Console running the UniFi Network Application for scalable deployment which supports 500+ UniFi devices and up to 5000+ simultaneous client connections. It can be configured and managed through the UniFi Network Application.

Ethernet Ports: 1x 10/100/1000/2500 (LAN); 1x 10/100/1000/2500 (WAN)
Hardware Button: Reset
Max. Power Consumption: 82W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: 0 to 40°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cable (Included)
Processor: 18-core ARM® v8.2 at 2GHz
Serial Interface: None
SFP Ports: 1x 25Gbps (LAN) 2x 10Gbps (LAN) 1x25Gbps (WAN)
Supported Voltage Range: 100-240V
System Memory: 16GB DDR4 DIMM
USB Ports: None

Dimensions: 442.4 x 43.7 x 325mm
Weight: 6.5kg

Ubiquiti's USW-E24XG is a layer 3 switch featuring 24x 10Gbps Ports, 2x 25Gbps SFP28 ports and a 1.3" LCM colour touchscreen with AR switch management.

It can be configured and managed with the UniFi Network Application.

*Note: The two SFP28 ports do not support mixed speed in 25 Gbps mode. Once one of the SFP28 ports is configured at 25 Gbps, the others will be limited at 25 Gbps. The SFP28 ports only support mixed speed when all ports are at 1Gbps or 10Gbps.
Ethernet Ports: 24x 10Gbps
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 25Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 442 x 44 x 285 mm
Weight: 4.57kg

Ubiquiti's USW-E8P is an 8 port, fully managed Layer 3 switch with 8x 2.5GbE, 802.3at PoE+ ports, 2x 10Gbps SFP+ ports and a PoE budget of 120W. The switch includes a wall mount kit and features a 1.3" LCM colour touchscreen to display key system and connection information.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 8x 100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop or Wall Mount (Kit Included)
Operating System: UniFi
Operating Temperature: -5°C to 45°C
PoE Input: None
PoE Output: 8x 802.3af/at
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 200 x 248 x 44 mm
Weight: 2.4Kg

Ubiquiti's UX is a compact UniFi Cloud Gateway with an integrated WiFi 6 access point that runs UniFi Network. The integrated WiFi 6 access point delivers an aggregate data rate of 3Gbps over 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It features an LCM (Liquid Crystal Monitor) colour screen to display key system and connection information.

The UX is configured and managed with the pre-installed UniFi Network Application.

For more information on how this device compares to the similar UXG-LITE read our blog post.

*Note: When running as a gateway and AP, the UX is limited to managing only 4 other UniFi devices. It does not support IPS/IDS.

Antenna Gain: 2.4GHz: 4dBi ; 5.8GHz: 5.15dBi
Beam-width: 360°
Data Rate: 2.4GHz: 573Mbps ; 5.8GHz: 2.4Gbps
Ethernet Ports: 1x 10/100/1000 (WAN); 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 45°C
PoE Input: None
PoE Output: None
Power Input: USB Type C (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 5V 3A
USB Ports: USB Type C (Powering device only)

Dimensions: 98 x 98 x 30 mm
Weight: 302g

Ubiquiti's UX is a compact UniFi Cloud Gateway with an integrated WiFi 6 access point that runs UniFi Network. The integrated WiFi 6 access point delivers an aggregate data rate of 3Gbps over 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands. It features an LCM (Liquid Crystal Monitor) colour screen to display key system and connection information.

The UX is configured and managed with the pre-installed UniFi Network Application.

For more information on how this device compares to the similar UXG-LITE read our blog post.

*Note: When running as a gateway and AP, the UX is limited to managing only 4 other UniFi devices. It does not support IPS/IDS.

Antenna Gain: 2.4GHz: 4dBi ; 5.8GHz: 5.15dBi
Beam-width: 360°
Data Rate: 2.4GHz: 573Mbps ; 5.8GHz: 2.4Gbps
Ethernet Ports: 1x 10/100/1000 (WAN); 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -10°C to 45°C
PoE Input: None
PoE Output: None
Power Input: USB Type C (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 5V 3A
USB Ports: USB Type C (Powering device only)

Dimensions: 98 x 98 x 30 mm
Weight: 302g

Ubiquiti's USW-5FLEX-2.5G is an indoor, compact, 5 Port 2.5Gbps switch that can be powered via PoE on Port 5 or via the included USB-C adapter. It can be configured and managed with the UniFi Network Application.
SKU USW-5FLEX-2.5G
Manufacturer Ubiquiti
Manufacturer Product Code USW-Flex-2.5G-5-EU
Ethernet Ports: 5x 10/100/1000/2500
Hardware Button: None
Max. Power Consumption: AC/DC: 5W ; PoE: 6.4W
Mounting: Desktop
Operating System: UniFi
Operating temperature: 20 to 45°C
PoE Input: 802.3af/at on Port 5
PoE Output: None
Power Input: 5V USB-C Adapter (Included) or PoE on Port 5
Serial Interface: None
SFP Ports: None
Supported Voltage Range: AC/DC: 5V ; PoE: 44-57V

Dimensions: 117.1 x 90 x 21.2 mm
Weight: 206g

Ubiquiti's USW-5FLEXMINI is an indoor, fully managed, 5 port, Gigabit UniFi switch with 1x 802.3af PoE+ input on port 1.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 5x 10/100/1000
Hardware Button: None
Max. Power Consumption: 2.5W
Mounting: Desktop
Operating System: UniFi
Operating temperature: -5°C to 45°C
PoE Input: 802.3af/at on Port 1
PoE Output: None
Power Input: 5V 1A USB-C Power Supply (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 4.7V-5.3V DC or 802.3af/at PoE

Dimensions: 107.16 x 70.15 x 21.17mm
Weight: 150g

Ubiquiti's USW-5FLEX is a managed, Layer 2, UniFi switch with 5x Gigabit Ethernet Ports. It includes 4x 802.3af PoE+ Ports and 1x 802.3af/at/bt PoE input. It is designed for indoor or outdoor use with its weatherproof housing and versatile mounting options. The USW-Flex provides both flexibility and durability for environments with extreme temperature variations.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
We recommend using the UPOE-48G60W or a Ubiquiti UniFi Switch to power these devices. When making use of the UPOE-48G60W, be sure to set the power source on the UniFi Network Application to injector.

Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 5W
Mounting: Desktop, Wall and Pole-Mount
Operating System: UniFi
Operating Temperature: -40°C to 55°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af on Ports 2~5
Power Input: 802.3af/at/bt on Port 1
Serial Interface: 1x RJ45 Ethernet In-Band
SFP Ports: None
Supported Voltage Range: 44–57V (802.3af) 50-57V (802.3bt)

Dimensions: 122.5 x 107.1 x 28.0mm
Weight: 230g

Ubiquiti's USW-FLEXU is an outdoor, weatherproof enclosure designed for use with the USW-5FLEX. Included with the unit are an Ethernet patch lead and a 60W PoE Injector providing a maximum PoE budget of 46W. The unit can be pole mounted and is easy to secure using the screw lock.

*Note: USW-5FLEX not Included.
US-FLEXU Specifications
Compatibility: US5-FLEX

Dimensions: 249 x 218 x 60mm
Weight: 740g

60W PoE Adapter Specifications
Ethernet Ports: 1x 10/100/1000
Operating Temperature: -20°C to 60°C
PoE Output: 54V 1.11A Passive PoE
Power Input: Terminal Block
Supported Voltage Range: 100V-240V

Dimensions: 118.5 x 63 x 34.7mm
Weight: 206g

Ubiquiti's ULTE-PRO is a wired backup LTE solution for existing UniFi networks. It features a Nano SIM slot and 2x Gigabit Ethernet Ports to provide a redundant WAN Connection. The device has 1x female RP-SMA connection should the user wish to add a higher gain antenna to the device.

*Note: This is not a stand-alone device. A UniFi Security Gateway, UniFi Dream Machine (UDM), or UniFi Dream Machine Pro (UDM-PRO) is required. PoE Injector not included.

Antenna Gain: LTE: 1.5dBi - 3.5dBi
Beam-width: 360°
Data Rate: LTE: 150Mbps Downlink; 50Mbps Uplink
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Wall Mount or Foot Stand (Included)
Operating System: UniFi
Operating Temperature: -10°C to 60°C
PoE Input: 802.3at PoE or Passive PoE (48V)
PoE Output: None
Power Input: 802.3at
Serial Interface: None
SIM Slots: 1 (Nano SIM)
Supported Voltage Range: 44-57V
USB Ports: None

Dimensions: 66 x 202 x 32 mm

Ubiquiti's UXG-PRO features a 1.7GHz quad-core processor, 1x Gigabit Ethernet and 1x SFP+ WAN ports with failover support. It also features 1x Gigabit and 1x SFP+ LAN Ports to support the most bandwidth-intensive applications. It offers a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and a layered firewall configuration.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 1x 10/100/1000 (WAN) : 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: IEC Power Cord (Included)
Processor: Quad-core 1.7GHz
Serial Interface: None
SFP Ports: 1x 10Gbps SFP+ (WAN) : 1x 10Gbps (LAN)
Supported Voltage Range: 200V–240V
System Memory: 2GB DDR4 RAM
USB Ports: None
Other: 1x IEC SmartPower outlet (200~240VAC/1.25A)

Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 3.42kg

Ubiquiti's UXG-PRO features a 1.7GHz quad-core processor, 1x Gigabit Ethernet and 1x SFP+ WAN ports with failover support. It also features 1x Gigabit and 1x SFP+ LAN Ports to support the most bandwidth-intensive applications. It offers a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and a layered firewall configuration.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 1x 10/100/1000 (WAN) : 1x 10/100/1000 (LAN)
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -10°C to 40°C
PoE Input: None
PoE Output: None
Power Input: IEC Power Cord (Included)
Processor: Quad-core 1.7GHz
Serial Interface: None
SFP Ports: 1x 10Gbps SFP+ (WAN) : 1x 10Gbps (LAN)
Supported Voltage Range: 200V–240V
System Memory: 2GB DDR4 RAM
USB Ports: None
Other: 1x IEC SmartPower outlet (200~240VAC/1.25A)

Dimensions: 442.4 x 43.7 x 285.6 mm
Weight: 3.42kg

Ubiquiti's UACC-UKPA is an IPx6, clip-on external antenna for the Swiss Army Knife (UK-ULTRA) that provides extended 90-degree directional coverage.
Antenna Gain: 2.4GHz: 10dBi ; 5.8GHz: 15dBi
Beam-width: 90°
Connector: 2x RP SMA Female
Wind Loading: 75 N at 200 km/h

Dimensions: 138 x 207 x 43 mm
Weight: 450g

Ubiquiti's USW-MAX16 is a 16 port, fully managed, Layer 3, Etherlighting™ switch. The unit features 12x Gigabit Ports, 4x 2.5Gbps ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fibre uplinks to your network.

Note: It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 325.1 x 160 x 43.7 mm
Weight: 1.95kg

Ubiquiti's USW-MAX16P is a 16 port, fully managed, Layer 3 Etherlighting™ switch. The switch includes a rack-mount kit for 10-inch racks and wall mounting. The UACC-MAX16P-RM accessory makes provision for 19 inch rack-mount deployments. The unit features a 180W PoE budget with 12x Gigabit PoE+ (802.3af/at) Ports, 4x 2.5Gbps PoE++ (802.3af/at/bt) ports and 2x SFP+ Uplink Ports. It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 12x 10/100/1000; 4x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop & 10-Inch Wall-Mount, or 19-Inch Rack Mount with UACC-MAX16P-RM (Not Included)
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 2.5Gbps: 4x 802.3af/at/bt ; Gigabit: 12x 802.3af/at
Power Input: 1x 54V, 3.9A, 210W DC adapter (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 54V

Dimensions: 325.1 x 160 x 43.7 mm
Weight: 2.1kg

Ubiquiti's USW-MAX24 is a 24 port, fully managed, Layer 3, Etherlighting™ switch. The unit features 16x Gigabit Ports, 8x 2.5Gbps ports and 2x SFP+ uplink Ports. This configuration makes provision for 2.5Gbps Ethernet as well as 10Gbps fibre uplinks to your network.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 16x 10/100/1000; 8x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 442 x 325 x 44 mm
Weight: 5.2kg
