Ubiquiti's U7-PRO-5 offers 5x U7-PRO in a single package. The units are Tri-Band, WiFi 7 access points with 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding environments. It delivers an aggregate data rate of up to 9.3Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.8dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 2.8Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø206 x 46 mm
Weight: 680g

Ubiquiti's U7-PRO is a Tri-Band WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding environments. It delivers an aggregate data rate of up to 9.3Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.8dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 2.8Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø206 x 46 mm
Weight: 680g

Ubiquiti's U7-PRO-IW is a Tri-Band, WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6GHz support for interference-free WiFi in demanding, large scale environments. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications

Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi : 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 4.3Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: 1 Gang Electrical Wall Box (Not Included)
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: 150 x 103 x 36 mm
Weight: 580g

Ubiquiti’s U6-MESH is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point with a compact IPX5 indoor/outdoor enclosure. It delivers an aggregate data rate of up to 5.3 Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11.4W
Mounting: Desktop ; Wall-Mount ; Pole Mount ; Ceiling Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af PoE
PoE Output: None
Power Input: 48V; 0.32A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44V-57V
USB Ports: None

Dimensions: Ø 48.50 x 159.49mm
Weight: 400g

Ubiquiti’s U6-MESH-PRO is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point featuring 2x Gigabit Ethernet ports, 4 spacial streams and integrated high power 8dBi antennas. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

Note: It can be configured and managed with the UniFi Network Application.
Antenna Gain: 2.4GHz: 8dBi ; 5.8GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop ; Wall-Mount ; Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af/at PoE
PoE Output: None
Power Input: 48V; 0.5A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5V-57V
USB Ports: None

Dimensions: 343.2 x 181.2 x 60.2 mm
Weight: 819g

Ubiquiti's U6+ is a dual band, WiFi 6 (802.11ax) access point. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included. The U6+ has replaced the UAP-AC-LR and U6-LITE. Read more about that here.
Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5.4dBi
Beam-width: 360
Data Rate: 2.4GHz: 573.5Mbps ; 5.8GHz: 2402Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af or 48V Passive PoE
PoE Output: None
Power Input: 802.3af/at or 48V Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø160 x 33 mm
Weight: 413g

Upgrade your multimedia experience with the Ubiquity VoIP & HDMI/DVI-IN Encoder. This innovative device lets you seamlessly stream high-quality video and audio content over IP networks. Simply connect your HDMI or DVI-IN sources, and you’re ready to go! Its built-in VoIP capabilities infuse audio into your video streams, delivering a comprehensive multimedia package. Ideal for use in conference rooms, classrooms and for digital signage applications, this versatile encoder is your solution to reliable high-quality streaming. Amp up your streaming game with the Ubiquity VoIP & HDMI/DVI-IN Encoder.

Experience the Marvel of the Ubiquity VoIP & HDMI/DVI-IN Encoder

Step into a world of unparalleled audio-visual mastery and discover the brilliance of Ubiquity VoIP & HDMI/DVI-IN Encoder. This innovative device combines the best of VoIP and content encoding technologies to deliver a seamless user experience.
The Power and Performance of Ubiquity VoIP & HDMI/DVI-IN Encoder

Instantly encode HD content and watch your favorite videos come to life.
Experience the amazing output quality with crystal clear sound and vibrant visuals.
Interact with various devices and mediums effortlessly through its highly compatible design.
Savor the sleek, compact and elegant design that ensures easy installation and saves space.
Stay connected with enhanced network connectivity for uninterrupted operation.

Beyond these amazing features, the Ubiquity VoIP & HDMI/DVI-IN Encoder also provides exclusive benefits such as:

Support for multiple video input resolutions allowing superb playback quality irrespective of the source.
Crisp and clear audio input and output capabilities that delivers pure sounds.
Flexible video output resolutions to cater to diverse display requirements.
Incorporation of powerful video and audio processing tools to ensure smooth and optimal performance.

Embrace the Future with Ubiquity VoIP & HDMI/DVI-IN Encoder: Being a limited edition piece, this encoder is the tech masterpiece that everyone wants. Make it yours before someone else does!

Enter a new era of content encoding and elevate your audio-visual experience. Add the Ubiquity VoIP & HDMI/DVI-IN Encoder to your cart and secure your piece before stocks run out!

Product SKU:PIN-MVX-E5150F

UltraLAN 10G SFP BiDi Module Pair - SM 10KM 1270/1330nm


UltraLAN's SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 10Gbps and 10km transmission distance with SMF.


The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.


Product Features:

Supports 10G rates
Bi-Directional LC connector
Hot pluggable SFP footprint
Applicable for 10KM SMF connection
Low power consumption, < 0.8W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection


Please note, as these are BiDi SFP Modules they are only sold in a pair.

UltraLAN 19" 700mm Flat Cabinet Shelf for 1000mm depth cabinets


The UltraLAN flat 19" shelf mounts on the side of the network cabinet upright struts (4-post mounting). With a depth of 700mm, it can provide for various needs within your cabinet. Ideal to provide support for non-rackmount items in a network cabinet such as routers, PBX's, and other equipment. The shelf is vented to help expel heat and improve air flow through the bottom. Flat cabinet shelves provides the largest surface area and supports a load up to 50KG.
Shelf dimensions: 465mm x 700mm


This model shelf is suitable for cabinets with an enclosure depth of 1000mm.


*Does not include cage nuts and screws for mounting.
All UltraLAN cabinets come with cage nuts & screws included, or they can be purchased separately.

UltraLAN 1x16 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x16 SC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x2 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x32 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x32 SC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x4 LC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:

Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x4 SC/APC 900μm PLC Splitter


Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.



Specifications:
Port Configuration
1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x8 900μm Bare Fiber Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

These bare fiber splitters have no connectors pre-terminated, giving customers the option to terminate their own preferred connectors (LC/SC/ST etc) depending on the equipment requirements.

UltraLAN 1x8 LC/APC 900μm PLC Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.


Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 1x8 SC/APC 900μm PLC Splitter

Planar Lightwave Circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to achieve optical signal power splitting.

Specifications:
Port Configuration 1x2 1x4 1x8 1x16 1x32
Operating Wavelength (nm) 1260～1650
Insertion Loss (dB) Typical 3.6 6.8 10.2 13.3 16.2
Max 4 7.4 10.5 13.5 16.9
Loss Uniformity (dB) Max 0.5 0.7 1 1.4 1.8
Return Loss (dB) Min 55 55 55 55 55
Polarization Dependent Loss(dB) Max 0.2 0.2 0.3 0.3 0.3
Directivity (dB) Min 55 55 55 55 55
Wavelength Dependent Loss(dB) Max 0.3 0.3 0.3 0.8 0.5
Temperature Dependent Loss (-40～85 ℃) (dB) Max 0.5 0.5 0.5 0.8 0.8
Operating Temperature (℃) -40～+85
Storage Temperature (℃) -40～+85

UltraLAN 24 Fiber Splice Tray


The UltraLAN fiber splice tray is designed to provide a place to store fiber cables and splices and prevent them from becoming damaged or being misplaced. These trays are commonly used individually/stand-alone, inside of fiber patch panels, or in large termination boxes.

The fiber splice tray has 4 access ports for fiber cable to either enter/exit the tray, allowing for cables to be easily fed into the tray from various angles. The tray is made from high strength injection mold plastic, is flame retardant, and offers a long anti-aging lifespan.


The UltraLAN fiber splice tray features 12 splice holder slots, but can also support a max of 24 splices when two sleeves are placed inside each slot. The cover and base section is securely joined with a metal pin, and the trays are stackable as well. The inner splice tray offers further cable management, with a fiber bend radius over 30mm.
