UltraLAN Fiber Flylead SC-SC UPC SM Simplex (20Meter)


The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack or as an end-point cable to link into a fiber ONT.


Connector Type SC to SC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade
G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead SC-SC UPC SM Simplex (20Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack or as an end-point cable to link into a fiber ONT.

Connector Type SC to SC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead SC-SC UPC SM Simplex (5Meter)


The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack or as an end-point cable to link into a fiber ONT.


Connector Type SC to SC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade
G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead SC-SC UPC SM Simplex (5Meter)

The UltraLAN 9/125μm OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G Ethernet connections. Being both cost effective and high performance, these cables are ideally suited for short distance equipment interconnects, such as linking data switches together in a network rack or as an end-point cable to link into a fiber ONT.

Connector Type SC to SC Polish Type UPC to UPC
Fiber Count Simplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Flylead ST-ST UPC SM Duplex (1Meter)


The UltraLAN high-quality ST to ST Single Mode Fiber flylead is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet applications.
The fiber optic cable has industry standard flammability rating LSZH (Low Smoke Zero Halogen) jacket and duplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.

This OS2 9/125μm single mode cable provides exceptional transmission performance and meets RoHS compliance.


Connector Type ST to ST Polish Type UPC to UPC
Fiber Count Duplex Fiber Mode OS2 9/125μm
Wavelength 1310/1550nm Fiber Grade
G.657.A1 (Compatible with G.652.D)
Insertion Loss ≤0.3dB Return Loss ≥50dB

UltraLAN Fiber Fusion Splicer and Tool Kit

The high-precision fusion splicer, with high-speed image processing and special precision positioning technology, can complete the whole process of fiber fusion splicing automatically in 8 seconds. It features 6 motors for precision alignment, and auto-focus cameras with 300x core magnification. The 5.5inch touch screen provides easy access to all functions and settings.


Convenient and Portable

Light weight, easy to carry and convenient to operate, the fusion machine provides fast splicing speed and low loses. The machine and accessories comes packaged in an easy to carry tool case, making it easy to travel with.


Industrial Grade Chipset

The internal core uses an industrial-grade 64bit low-power processor, with powerful decoding capabilities, and rich interfaces, which will not crash or freeze in harsh environments.


Built-In VFL and OPM

The fusion splicer has both a red light source laser built in (for visual fault locating) as well as a Optical Power Meter to measure dBm levels, especially important for FTTH applications with GPON.


All-in-One Kit

This comprehensive package includes all of the items that you require to successfully splice and join fiber cables in the field. The tool kit includes the following:

Fiber fusion splicer (welding machine)
Rechargeable lithium battery
Power adapter/charger
Fiber cleaver
Miller clamp (to remove fiber sheath)
Fiber drop cable jacket remover
Bottle (for cleaning solution)
Spare pair of electrodes

UltraLAN Fiber Mini Power Meter


Main Features:

LCD color screen for easy reading
Mini Optical power meter to measure fiber loss
With memory wavelength function
Able to identify working frequency
Supports user calibration
Support SC, FC, ST interface
Support linear (nW) and non-linear indicators (dB)
Lithium battery for power supply, or external power supply
Technical Parameters:
Wavelength range 800~1700
Probe type InGaAs
Measuring range -70~+3 , -50~+26 (optional)
Uncertainty ±5%
Standard wavelength (nm) 850/980/1300/1310/1490/1550/1625
Display resolution Linear display: 0.1%,
logarithmic display: 0.01dBm
Frequency identification(Hz) 0/270/1000/2000
Battery life(h) ≥20
Charging voltage(v) 5
Detection area 300um
Charging time(h) ≤3
Power supply Rechargeable lithium battery, external input

UltraLAN Fiber Optic Cable Stripper


This rugged tool features a 1.0mm radiused blade and a 140µm V blade specifically designed for stripping jacket and buffer from 125 micron fiber. An ergonomically designed handle reduces user fatigue. This tool is a must for every fiber installer.


Features:

Used to strip fiber optic cables
Ergonomic handle design reduces hand fatigue
Dual function, strips jacket and buffer at the same time
For use with 125 micron fiber cables

UltraLAN Fiber Optic Tool Kit


The UltraLAN Fiber Optic Tool Kit is a must-have essential for any fiber field technician or installer.
The tool kit comprises of the following items:


Fiber Power Meter

The UltraLAN Fiber Power Meter is portable and easy to carry in the field. It features a large readout screen with LED back light.
The meter has a wide testing range and offers seven calibrated wavelengths - 850nm, 980nm,1300nm, 1310nm, 1490nm, 1550nm, 1625nm
Measurements range from -70 - +6 dB.


10mW Visual Fault Locator

The Visual Fault Locator can be used to inspect optical fiber cables and connectors for potential failures and issues when connected to an optical interface and/or with a single mode or multi-mode optical fiber.


Fiber Stripper

This rugged tool features a 1.0mm radiused blade and a 140µm V blade specifically designed for stripping jacket and buffer from 125 micron fiber. An ergonomically designed handle reduces user fatigue.


Fiber FTTx Drop Cable Stripper

The fiber drop cable stripper is designed for stripping flat fiber drop cable used in Fiber to the Home (FTTH) applications. The tool removes the jacket in two locations to expose the dielectric strength members and allowing quick removal of the fiber cable jacket.


Fiber Cleaver

The ultimate tool for single and ribbon cleaving. Built on a robust high-quality platform, the UltraLAN fiber cleaver is ideal for use with fusion splicing or other precision applications, setting a new standard for flexibility and performance. By using a rotating blade for multiple scoring positions enables a typical blade life of 36000 cleaves or more, with a cleave angle better than 0.5 degrees.


Easy to Carry Tool Bag

UltraLAN Fiber Pigtail - LC APC SM Simplex 0.9m

UltraLAN fiber optic pigtails provide a fast way to make communication links in the field, and are also commonly used for termination inside patch panels and termination boxes. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet the most stringent mechanical and performance specifications.

Connector A LC Connector B Unterminated
Fiber Mode 9/125 μm Fiber Count Simplex
Fiber Grade G.652.D Minimum Bend Radius 30 mm
Polish Type APC Wavelength 1310 nm/1550 nm Insertion Loss ≤0.3 dB Return Loss ≥60 dB

UltraLAN Fiber Pigtail - LC UPC SM Simplex 0.9m

UltraLAN fiber optic pigtails provide a fast way to make communication links in the field, and are also commonly used for termination inside patch panels and termination boxes. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet the most stringent mechanical and performance specifications.

Connector A LC Connector B Unterminated
Fiber Mode 9/125 μm Fiber Count Simplex
Fiber Grade G.652.D Minimum Bend Radius 30 mm
Polish Type UPC Wavelength 1310 nm/1550 nm
Insertion Loss ≤0.3 dB Return Loss ≥50 dB

UltraLAN Fiber Pigtail - SC APC SM Simplex 0.9m

UltraLAN fiber optic pigtails provide a fast way to make communication links in the field, and are also commonly used for termination inside patch panels and termination boxes. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet the most stringent mechanical and performance specifications.

Connector A SC Connector B Unterminated
Fiber Mode 9/125 μm Fiber Count Simplex
Fiber Grade G.652.D Minimum Bend Radius 30 mm
Polish Type APC Wavelength 1310 nm/1550 nm
Insertion Loss ≤0.3 dB Return Loss ≥60 dB

UltraLAN Fiber Power Meter


Power meters are a toolbox essential for all technicians installing or maintaining any type of fiber networks. The UltraLAN Fiber Power Meter is portable and easy to carry in the field. It features a large readout screen with LED back light.

The meter has a wide testing range and offers seven calibrated wavelengths - 850nm, 980nm,1300nm, 1310nm, 1490nm, 1550nm, 1625nm
Measurements range from -70 - +10 dB.


Specifications:

Probe Type: InGaAs
Wavelength Range: 800~1700nm
Display Resolution: Linear Display 0.1%; Logarithmic display 0.01dB
Working Temp(℃): -10~+60℃
Storage Temp(℃): -25~+70℃
Auto Switch-off Time: 10min

UltraLAN Fiber Power Meter with VFL


The UltraLAN optical power meter is a compact and an easy-to-use testing instrument for optical fiber networks, which can be used for absolute optical power measurements as well as for optical fiber winding or breakage fault finding. The power meter features a wide range of laser frequencies, making it a great tool for testing any fiber network. The highly accurate power meter is invaluable when implementing PON networks to insure devices such as ONT/ONU's are receiving the correct power levels within the specified limit for a PON fiber setup.


Main Features:

Measurement of the power of optical sender (dBm and W).
Insertion loss test of optical devices.
Check fiber breakage, winding, etc. with the Visual Fault Locator
FC, SC, ST, LC switchable (FC is included originally)
6 Wavelength: 850 / 1300 / 1310 / 1490 / 1550 / 1625nm (power meter)
Wavelength: 650nm ( visual fault locator)
Specifications:
Power detecting range(dBm) -70~+3
Probe InGaAs
Detection limit ∮1.0mm
Standard wavelength 850,980,1300, 1310, 1490, 1550, 1625nm
Display resolution 0.01dBm
Emitting Energy 15km
Standard wavelength (VFL) 650±10nm
Working temp -20 ~ +70℃
Power supply AA*3pcs

UltraLAN Fiber Power Meter with 10mw VFL


The UltraLAN Fiber Power Meter and Visual Fault Locator (VFL) is a handheld optical power meter, which also conveniently includes a built-in laser based Visual Fault Locator. The ergonomically designed instrument uses advanced technology for outstanding functionality and durability.


The power meter uses microprocessor control and includes a variety of advanced features and user selectable settings. It is used for optical signal power measurement at a variety of wavelengths from 800-1700nm. The Visual Fault Locator can be used to inspect optical fiber cables and connectors for potential failures and issues when connected to an optical interface and/or with a single mode or multi-mode optical fiber.


It is an indispensable tool in fiber project installations, construction, fiber network maintenance, for testing fusion or field-installed connectorized cables, optical component manufacture and research, etc.

UltraLAN Fiber Termination Box (1port) & Installation Pack


UltraLAN's 1 port termination box is used for fiber termination inside a building. It supports one LC or SC connector (midcoupler not included) and a small tray for better pigtail and splicing management.

This sleek design also provides additional robustness to your installation with a cover plate to protect the sensitive connection between the patch lead and the termination box itself.


The termination box is also supplied with a value added Installation Pack consisting of:

2 cable ties to secure your fiber cable inside the box
2 coach screws and plugs for wall mounting the box

UltraLAN Fiber Termination Box (2port) & Installation Pack


UltraLAN's 2 port termination box is used for fiber termination inside a building. It supports two LC or SC connectors (midcouplers not included) and a small tray for better pigtail and splicing management.


This sleek design also provides additional robustness to your installation with a cover plate to protect the sensitive connection between the patch lead and the termination box itself.


The termination box is also supplied with a value added Installation Pack consisting of:

2 cable ties to secure your fiber cable inside the box
2 coach screws and plugs for wall mounting the box
2 fibre splice protectors

UltraLAN Fiber Distribution Box (8port) & Installation Pack


UltraLAN's 8 port distribution box is commonly used for fiber termination inside a building. It supports eight LC or SC connectors (midcouplers not included) and a small tray for better pigtail and splicing management.


The termination box is also supplied with a value added Installation Pack consisting of:

cable ties to secure your fiber cable inside the box
coach screws and plugs for wall mounting the box
fibre splice protectors

UltraLAN Fiber to Gigabit Converter PSU (5V 2A)


This power supply is intended for use with the UltraLAN Fiber to Gigabit Ethernet convertor.
Features a SA 3pin power plug on side, and a DC barrel on the other.


Product Specifications

Input Voltage: 100-250 V AC
Input Frequency: 50-60Hz 0.28A
Output Voltage: 5V DC 2.0A
SA 3pin power plug
DC Barrel on output of PSU

UltraLAN Fiber to Gigabit RJ45 Converter

The UltraLAN FIB-MCGSFP is a media converter designed to convert fiber to 10/100/1000Base-T copper media or vice versa.
The UltraLAN media converters are compatible with a wide range of transceiver modules, such as general 1000Base SFP transceiver modules, BiDi transceiver modules, CWDM transceiver modules, etc. The media converter is unmanaged and requires no configuration, simply plug-and-play.

Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX standards, the FIB-MCGSFP is designed for use with multi-mode or single-mode fiber SFP modules. The fiber media converter supports 850nm/1310nm/1550nm wavelengths depending on the SFP module that is inserted. Other features of this media converter include Auto MDI/MDI-X for TX port and status LED's (Link speed, Link activity, Power).

Product Features:

Gigabit copper to fiber conversion: 10/100/1000Base-T-to-1000Base-X
SFP design: For flexibility, an SFP (Mini-GBIC) slot is provided for the fiber port to support any type of SFP fiber transceiver when needed.
Supports full wire speed copper-to-fiber conversion
Auto MDI/MDI-X detection function on the copper port
Auto-negotiation support
Plug and play: no configuration settings is required
Low power consumption
