UltraLAN Fusion Splicer Power Supply

Keep your UltraLAN Fusion Splicer operational with our reliable power supply. Whether you need a spare or a replacement, this power supply ensures your equipment stays powered up and ready for any task. Designed specifically for the UltraLAN Fusion Splicer, it offers seamless compatibility to keep your splice machine charged.

Features:
Input: AC 100-240V, 50/60Hz, 1.4A Max
Output: DC 13.6V, 5A

Please Note:
The power supply is sold without a power cord. A compatible power cord can be purchased separately

UltraLAN GPON ONT (HGU - SC/APC)

A robust, high-performance Fiber GPON CPE that features extremely low power consumption with fast bandwidth speeds. Supports GPON links of up to 20km, with a max downstream speed of 2.5Gbps, and upstream rate of 1.25Gpbs. The ONT is compatible with major 3rd party vendor's OLT units. This is a HGU (Home Gateway Unit) ONT.

Features:

GPON mode (can access GPON OLTs).
Plug and play, integrate auto detection, auto configuration and auto firmware upgrades.
Support downstream 2.5Gbps and upstream 1.25Gbps with transmission distance to 20km.
Fiber access and gigabit port provide incredibly fast transfer speeds.
Supports OMCI (ONT Management Control Interface) remote management.
Support IPv4/ IPv6 IGMP snooping and MLD snooping.
Support bridge, route and bridge/route mixed mode.


Differences between SFU and HGU ONT's:

SFU ONT HGU ONT Type of PON EPON / GPON EPON / GPON
EPON/GPON Standard IEEE 802.3/802.3ah ITU-TG.984.x IEEE 802.3/802.3ah ITU-TG.984.x
Bridging /Routing Bridging/L2 Bridging/L2 and Routing/L3
WAN Configuration Not Supported Supported
TR069 Function Not Supported Supported
OLT to configure its Ethernet Ports Supported Not Supported
NAT Function Not Supported Supported
Port Forwarding Function Not Supported Supported
Loop Detection Function Supported Not Supported
DHCP Server Not Supported Supported

Specifications:

Distance
20km Maximum
Data Rates
Upstream rate 1.25Gbps
Downstream rate 2.5Gbps
PON TX Power
1~5dBm (1310nm)
PON RX sensitivity
<-28dBm (1490nm)
Power
≤ 3W
Interfaces
1x SC/APC PON (Passive Optical Network) Port
1x 10/100/1000Mbps LAN port
Buttons
Reset Button
Power Supply
DC 12V 0.5A
Operating Temperature
-10°C~50°C
Storage Temperature
-40°C~70°C
Operating Humidity
10%~90%, non-condensing
Storage Humidity
5%~90% non-condensing
WAN Type
Dynamic IP/Static IP/PPPoE
DHCP
Server, Client, DHCP Client List, Address Reservation
Quality of Service
Bandwidth Control
Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
VLAN
Port-based VLAN, IEEE802.1Q VLAN
Access Control
Local Management Control, Host List, Access Schedule, Rule Management
Route
Support NAT, Support PPPOE, Support Server Client, Support Route
Firewall Security
DoS, SPI Firewall, IP Address Filter/MAC Address Filter, Domain Filter, IP and MAC Address Binding

UltraLAN GPON SFP Class C++ SC/UPC for OLT (FIB-SFP-GP-C++)

The UltraLAN GPON SFP Class C++ module is engineered for high-performance Gigabit-capable Passive Optical Networks (GPON), offering seamless integration with Fiber OLT units. With a bi-directional data link supporting 2488Mbps transmit and 1244Mbps receive rates, this module features a compact SC/UPC connector, operates within a temperature range of 0 to 70°C, and is powered by a single 3.3V supply. Designed for reliability, it includes advanced digital diagnostics, low EMI, and robust ESD protection, all while adhering to stringent safety and compliance standards. Enhance your network's efficiency with this cutting-edge SFP module.

Applications:

• Gigabit-capable Passive Optical Networks (GPON)

Features:

• Single fiber bi-directional data links asymmetric TX 2488Mbps/RX1244Mbps application

• 1490nm continuous-mode DFB laser transmitter and 1310nm burst-mode APD-TIA receiver

• Small Form Factor Pluggable package with SC/UPC Connector

• 0 to 70°C operating temperature

• Single 3.3V power supply

• Digital diagnostic monitoring interface

• Digital burst RSSI function to monitor the input optical power level

• LVPECL compatible data input/output interface

• LVTTL transmitter disable control

• LVTTL transmitter laser fault alarm

• Fast LVTTL receiver Signal Detect (SD) indication response

• Low EMI and excellent ESD protection

• Class I laser safety standard IEC-60825 compliant

• RoHS6 Compliance

Standards:

• Complies with SFP Multi-Source Agreement (MSA) SFF-8074i

• Complies with ITU-T G.984.2 Amendment 1

• Complies with FCC 47 CFR Part 15, Class B

• Complies with FDA 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007

• Complies with SFF-8472

• Compatible with TR-NWT-000870 4.1 ESD sensitivity classification Class2.

• Compatible with Telcordia GR-468-CORE

UltraLAN Gigabit RJ45 SFP Module - 10/100/1000 Ethernet Module


The UltraLAN Copper Small Form Pluggable (SFP) transceivers are high performance, cost effective modules compliant with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supports up to Gigabit data rates up to 100 meters in distance over unshielded twisted-pair CAT5 cabling.


The module supports 1000Mbps (or 10/100/1000Mbps) full duplex data-links with 5-level Pulse Amplitude Modulation (PAM) signals. All four pairs in the cable are used with symbol rate at 250Mbps on each pair.


This SFP module is compatible with all vendor devices that has an SFP slot.

Product Features:

Gigabit bi-directional data links
Compact RJ-45 connector
Hot pluggable SFP footprint
1 Gigabit Ethernet over CAT5 cable
Applicable for 100m distance transmission
Low power consumption, < 1.2W
Access to physical layer IC via 2-wire serial bus

UltraLAN High Precision Fiber Optic Cleaver


The ultimate tool for single and ribbon cleaving. Built on a robust high-quality platform, the UltraLAN fiber cleaver is ideal for use with fusion splicing or other precision applications, setting a new standard for flexibility and performance. By using a rotating blade for multiple scoring positions enables a typical blade life of 36000 cleaves or more, with a cleave angle better than 0.5 degrees.

The UltraLAN fiber cleaver is available with a single fiber adapter for 250 to 900 micron coated single fibers. It is a simple operation for the user to remove or install the single fiber adapter and alternate between mass and single fiber cleaving.


Product Features:

Used for Mass or Single Fiber Cleaving
Utilizes an Automatic Anvil Drop for easy of use and provides better cleave consistency
Prevents Double Scoring of the Fibers.
Has Superior Blade Height and Rotational Adjustment.
Can Be Operated With Minimal Steps

305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m Box

Conductor material: Solid Bare Copper

Conductor diameter: 0.51mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

UltraLAN Installer Series - CAT5e CCA Solid UTP (100m)


100m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 100m Easy Pull Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

UltraLAN Installer Series - CAT5e CCA Solid UTP (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Packaging dimensions: 22x35x35cm

Gross weight: 7.6kg

UltraLAN Installer Series - CAT5e CCA Solid UTP (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices! This cable features a blue colored outer jacket for easier cable identification.

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.


General Specifications

Packaging: 305m Easy Pull Box

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Blue

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (100m)

100m Box of UltraLAN Installer Series UV-resistant CAT5e Ethernet cable with drain wire suitable for outdoor networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

A drain wire provides the ability to ground outdoor networking equipment, reducing risk of damage to the hardware as a result of ESD or storm activity. Shielded RJ45 connectors should be used and all power supplies and/or injectors properly grounded to get the benefits of this high-quality cable.

UltraLAN's Installer Series Outdoor cable dramatically increases Ethernet link states, speeds and overall performance. It has been designed and manufactured to perform in the harshest weather environments and is suitable for any outdoor applications that requires robust and reliable cabling.
Multi-layered UV protected cable sheath allows for superior protection from the elements.
FTP (Foil Twisted Pair) cable provides excellent external interface mitigation.
Drain wire provides additional protection from ESD.
Meets and exceeds CAT5e rating (suitable for Gigabit applications).

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (305m)

305m Drum of UltraLAN Installer Series UV-resistant CAT5e Ethernet cable with drain wire suitable for outdoor networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

A drain wire provides the ability to ground outdoor networking equipment, reducing risk of damage to the hardware as a result of ESD or storm activity. Shielded RJ45 connectors should be used and all power supplies and/or injectors properly grounded to get the benefits of this high quality cable.

UltraLAN's Installer Series Outdoor cable dramatically increases Ethernet link states, speeds and overall performance. It has been designed and manufactured to perform in the harshest weather environments, and is suitable for any outdoor applications that requires robust and reliable cabling.

FTP (Foil Twisted Pair) cable provides excellent external interface mitigation.
Drain wire provides additional protection from ESD.
Meets and exceeds CAT5e rating (suitable for Gigabit applications).

UltraLAN Installer Series - CAT5e CCA Outdoor FTP (500m)

500m Drum of UltraLAN Installer Series UV-resistant CAT5e Ethernet cable with drain wire suitable for outdoor networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

A drain wire provides the ability to ground outdoor networking equipment, reducing risk of damage to the hardware as a result of ESD or storm activity. Shielded RJ45 connectors should be used and all power supplies and/or injectors properly grounded to get the benefits of this high quality cable.

UltraLAN's Installer Series Outdoor cable dramatically increases Ethernet link states, speeds and overall performance. It has been designed and manufactured to perform in the harshest weather environments, and is suitable for any outdoor applications that requires robust and reliable cabling.
Multi-layered UV protected cable sheath allows for superior protection from the elements.
FTP (Foil Twisted Pair) cable provides excellent external interface mitigation.
Drain wire provides additional protection from ESD.
Meets and exceeds CAT5e rating (suitable for Gigabit applications).

UltraLAN Installer Series - CAT5e Solid UTP (500m)


500m roll of UltraLAN CAT5e Installer Series solid-core Ethernet bulk cable suitable for everyday networking installations.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.




General Specifications

Packaging: 500m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: Grey

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Gross weight: 13.5kg

UltraLAN Installer Series - CAT5e CCA Solid UTP WHITE (305m)


305m box of UltraLAN CAT5e Installer Series solid-core Ethernet cable suitable for everyday networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.

General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.50mm

Colour: White

Operation temperature range: -20°C~60°C

Minimum bending radius: 60mm

Packaging dimensions: 22x35x35cm

Gross weight: 7.6kg

UltraLAN Installer Series - CAT6 Bare Copper Solid UTP (305m)


305m Box of UltraLAN CAT6 Installer Series solid-core Bare Copper Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m Box

Conductor material: Solid Bare Copper

Conductor diameter: 23AWG

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 Bare Copper Solid UTP (500m)


500m Drum of UltraLAN CAT6 Installer Series solid-core Bare Copper Ethernet cable suitable for high performance networking installations.

The new Installer Series Cabling features the same quality and reliability from UltraLAN, now designed especially for networking professionals and available at unbeatable prices!

UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 500m Drum

Conductor material: Solid Bare Copper

Conductor diameter: 23AWG

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (305m - Grey)


305m box of Ultra LAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Grey

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (305m)

305m box of Ultra LAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 305m roll

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Blue

Operation temperature range: -20°C~60°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (500m - Grey)


305m box of UltraLAN CAT6 solid CCA Ethernet cable for high-performance networks. This cable has a grey cable jacket which blends better in environments when no trunking/ducting is used (in comparison to the standard blue color CAT6).
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient.
General Specifications

Packaging: 500m Drum

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Grey

Operation temperature range: -20°C~70°C

UltraLAN Installer Series - CAT6 CCA Solid UTP (500m)

500m Drum of UltraLAN CAT6 solid CCA Ethernet cable for high-performance networks.
UltraLAN cable is ideal for high capacity traffic networks, provides better power conduction, and is more resilient

General Specifications

Packaging: 500m Drum

Conductor material: Solid Copper-Clad Aluminium (CCA)

Conductor diameter: 0.57mm

Colour: Blue

Operation temperature range: -20°C~70°C
