UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 30m

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 30m White

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 60m

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 60m

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 60m White

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 90m

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Pre-Terminated Drop Cable (LC/APC) Simplex - 90m White

UltraLAN's pre-terminated fiber drop cables are cost effective cable assemblies designed for linking FTTX equipment together easily and quickly, without the need for splicing.

This cable is a ‘Bow Type’, Single Mode, 1 core (simplex), FTTX cable which has LC APC connectors pre-terminated on both sides. The outer jacket is 2x3mm and made from UV resistant, Low Smoke Zero Halogen (LSZH) material. As the cable adheres to G657A2 specs, it is bend-insensitive, making for easier installations for both indoor or outdoor applications.

The cable is also supported by two 0.45mm phosphate wires internally, giving reinforcement to the cable when bending around corners and improving pull strength.

UltraLAN Punch Down / Krone Tool


Multi-purpose punch down / Krone tool for the construction of Ethernet RJ45, RJ11 and RJ12 cables.


Features:

Universal scissors cut a variety of cable types, including 20 AWG through to 26AWG, and Type 1 foam-insulated conductors.
A blade helps to easily remove the blocks from back mount frames.
Insertion Sensor ensures the conductor is fully inserted into the block contacts before allowing any excess wire to be cut off.
Suitable for connecting cables, modules and distribution frames
Multi-purpose cutter and stripper for data, telephone and network installations
Works with Cat3, Cat5, Cat5e, Cat6 shielded and non-shielded cable.
Wire Hook removes terminated conductors.
Made from high quality steel
Easy to use, portable, and cost effective

UltraLAN QSFP Module - 40G MM 150m 850nm


UltraLAN's FIB-SFP-ULSQ854XM-CDS1 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Transceiver for 40 Gigabit Ethernet Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications.


It integrates four data lanes in each direction with 40 Gbps bandwidth.one version is Each lane can operate at 10.5Gbps up to100m using OM3 or 150m using OM4 Multimode fiber,another version is Each lane can operate at 10.5Gbps up to300m using OM3 or 400m using OM4 Multimode fiber. These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm.


The electrical interface uses a 38 contact edge type connector. The optical interface uses an 12 fiber MTP (MPO) connector. This module incorporates proven circuit and VCSEL technology to provide reliable longlife, high performance, and consistent service.


Product Applications:

40GBASE-SR4 40G Ethernet
Data communication/Telecoms switches & router connections
Data Aggregation and Backplane Applications
Proprietary Protocol and High Density Applications
Infiniband transmission at 4CH SDR, DDR and QDR
Other optical links


Product Features:

Supports 1.06 to 10.5Gb/s bit rates per Channel
Four-Channel ,1x12 MPO receptacle
Hot pluggable QSFP+ form factor
VCSEL 850nm array Technology
Applicable for 100m on OM3 MMF, 150m on OM4 MMF.
Built-in digital diagnostic functions
Low power consumption, < 1.5W
Unretimed XLPPI electrical interface
Operating case temperature: -5°C to 80 °C

UltraLAN QSFP+ 40G DAC Cable - 1meter

RoHS Compliant 40Gb/s QSFP+ TO QSFP+ Copper Cable Assembly

The UltraLAN QSFP+ to QSFP+ Passive cable assemblies are high performance and cost effective QSFP+ equipment interconnect cables . The hybrid cables are compliant with SFF-8436 and SFF-8431 specifications.

These DAC cables are ideal for short distance interconnect applications, such as linking high speed core switches or telecom routers together in a rack/cabinet. While still having a low power consumption, these cables provide an aggregated data rate of 40Gb/s.

Product Applications:

High capacity I/O in SAN (Storage Area Networks), NAS (Network Attached Storage), and Storage Servers
Switched fabric I/O such as ultra high bandwidth switches and routers
Data center cabling infrastructure
High density connections between networking equipment

Product Features:

Support for multi-gigabit data rates up to 40Gbps
Hot-pluggable QSFP+ footprint
Available in lengths of 0.5,1, 2, 3, 5 m
Metal with lower EMI
Low Power Consumption < 0.5W
Power Supply :+3.3V
Compatible to QSFP+ MSA standards
Temperature Range: 0~ 70 ° C

UltraLAN Part Code Matrix:

UltraLAN RG59 BNC Crimp Connector (Male)


BNC Connectors are commonly used for video transmission applications such as broadcast and CCTV as well as in radio and test equipment. These UltraLAN connectors are 75 Ohm rated and suitable for all RG59 Coaxial cables.

This connector requires a crimping tool for proper termination. View the UltraLAN RG59/Coaxial crimping tool

UltraLAN RG59 CCS Siamese Coax & Power Cable (305m)


The UltraLAN RG59 Siamese Coaxial Cable features a copper coated steel coaxial cable paired with 2x power wires to simplify installations. This cable allows CCTV installers to run both video and power to security cameras using a single cable run.


The coaxial cable is 75 Ohm and has a metal braid for reduced interference. This is a cost effective RG59 cable for security, surveillance and CCTV applications where one needs to distribute video and power to cameras in remote locations

UltraLAN RG59 Siamese Coax & Power Cable (305m)

The UltraLAN RG59 Mil Spec Siamese Coaxial Cable features a bare copper 0.81mm coaxial cable paired with 2x 0.5mm power wires to simplify installations. This cable allows CCTV installers to run both video and power to security cameras using a single cable run.

The coaxial cable is 75 Ohm and has a solid copper conductor (bare copper), along with a metal braid for reduced interference. This is an ideal cable for security, surveillance and CCTV applications where one needs to distribute video and power to cameras in remote locations.

The UltraLAN professional crimping tool is ideal for individuals needing to make up coax cables with crimped connections (suitable for N-Type, BNC, and TNC connectors). The tool features a lightweight steel body for easier handling, as well as a ratchet handle to apply force easier when crimping a connector.

The crimping tool has a die set (HT-336A) with 3 hexagonal openings for crimping connectors, making it suitable for a variety of cables (RG58, RG59, and RG62):
.256" / 6.50mm hexagon slot,
.068" / 1.7mm hexagon slot,
.213" / 5.41mm hexagon slot.

UltraLAN SC/APC Fast Connector


The UltraLAN SC Fast Connector can easily and quickly be installed onto fiber cabling while in the field.

These fast connectors allows the fiber installer to terminate and make connection in minutes at equipment and fiber patch panels.

UltraLAN SFP BiDi Module Pair - SM 20KM 1310/1510nm


UltraLAN's SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 20km transmission distance with SMF.


The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.


Product Features:

Supports 1.25Gbps/1.0625Gbps bit rates
Bi-Directional LC connector
Hot pluggable SFP footprint
Applicable for 20Km SMF connection
Low power consumption, < 0.8W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection


Please note, as these are BiDi SFP Modules they are only sold in a pair.

UltraLAN SFP BiDi Module Pair - SM 3KM 1310/1510nm


UltraLAN's SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 3km transmission distance with SMF.


The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.


Product Features:

Supports 1.25Gbps/1.0625Gbps bit rates
Bi-Directional LC connector
Hot pluggable SFP footprint
Applicable for 3KM SMF connection
Low power consumption, < 0.8W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection


Please note, as these are BiDi SFP Modules they are only sold in a pair.

UltraLAN SFP Module - Multimode 1.25G 500m 850nm


The UltraLAN SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF.

The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.


Product Features:

Supports 1.25Gbps/1.0625Gbps bit rates
Duplex LC connector
Hot pluggable SFP footprint
850nm VSCEL laser transmitter and PIN photo-detector
Applicable for 500m on 50/125µm, 300m on 62.5/125µm MMF connection
Low power consumption, < 0.5W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection

UltraLAN SFP Module - Single Mode 1.25G 10KM 1310nm


UltraLAN SFP transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 10km transmission distance with SMF.


The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.


Product Features:

Supports 1.25Gbps/1.0625Gbps bit rates
Duplex LC connector
Hot pluggable SFP footprint
1310nm FP laser transmitter and PIN photo-detector
Applicable for 10Km SMF connection
Low power consumption, < 0.8W
Digital Diagnostic Monitor Interface
Compliant with SFP MSA and SFF-8472
Very low EMI and excellent ESD protection
Very low EMI and excellent ESD protection
