Ubiquiti's USW-24 is a managed, Layer 2, UniFi switch. It has 24x Gigabit Ethernet ports and 2x 1.25Gbps SFP uplink ports. The unit features a fanless design with a 1.3" touchscreen that displays the current switch state and other information for quick and easy reference.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 200 x 43.7 mm
Weight: 2.79kg

Ubiquiti's USW-48P is a managed Layer 2 switch with 48x Gigabit Ports. It includes 32x 802.3at PoE+ ports, 4x 1.25Gbps SFP uplink ports and a PoE budget of 195W. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1~32
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 285 x 43.7mm
Weight: 4.61kg

Ubiquiti's USW-48 is a managed, Layer 2, UniFi switch. It features 48x Gigabit Ethernet ports and 4x 1.25Gbps SFP uplink ports. The unit features a fan-less design and a 1.3" touchscreen with AR switch management which displays the current switch state and other information for quick, easy reference.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 40W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -15°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 1.25Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 285 x 43.7 mm
Weight: 4kg

Ubiquiti's USW-LITE16P is a fully managed layer 2 switch with 16x Gigabit Ethernet ports, 8x 802.3af/at PoE+ ports and a PoE budget of 45W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fanless, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 100 to 240VAC

Dimensions: 99.6 x 163.7 x 31.7mm
Weight: 450g

Ubiquiti's USW-LITE8P is a fully managed, Layer 2, UniFi switch with 8x Gigabit Ethernet ports, 4x auto-sensing 802.3at PoE+ ports and a PoE budget of 52W. The device offers an extensive suite of advanced layer 2 switching protocols and features. A wall-mountable kit is included with the switch. The device is fanless, meaning that it will be silent no matter where it is used.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Desktp or Wall-Mount
Operating System: UniFi
Operating Temperature: -15 to 40° C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 4
Power Input: 54V 1A Power Supply (Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 50-57V

Dimensions: 99.6 x 163.7 x 31.7 mm
Weight: 450g

Ubiquiti's USW-PRO24P is a fully managed 24-Port Gigabit Layer 3 UniFi switch. It has 16x 802.3at PoE+ Ports, 8x 802.3bt PoE++ Ports, 2x 10Gbps SFP+ and a PoE budget of 400W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 16x 802.3af/at ; 8x 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 442.4 x 285.4 x 43.7mm
Weight: 4.39kg

Ubiquiti's USW-PRO24 is a fully managed, Layer 3, UniFi switch with 24x Gigabit Ports and 2x 10G SFP+ uplink ports. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information. It offers a rich set of layer 2 capabilities with integrated layer 3 functionality.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max Power Consumption: 30W
Mounting: Rack-Mount
Operating System: UniFi
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100 to 240VAC

Ubiquiti’s USW-PRO48P is a fully managed 48-Port Gigabit Layer 3 UniFi Switch. It has 40x 802.3at PoE+ Ports, 8x 802.3bt PoE++ Ports, 4x 10Gbps SFP+ and a PoE budget of 600W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: Ports 1~40 802.3af/at ; Ports 41~48 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 399.6 x 43.7mm
Weight: 6.34kg

Ubiquiti's USW-PRO48 is a fully managed Layer 3 switch with 48x Gigabit Ethernet Ports and 4x 10Gbps SFP+ Uplink Ports. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: UniFi
Operating temperature: -5°C to 45°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 285.4 x 43.7 mm
Weight: 4.09kg

Ubiquiti's USW-PRO8P is a fully managed 8-Port Gigabit Layer 3 UniFi switch. It has 6x 802.3at PoE+ Ports, 2x 802.3bt PoE++ Ports, 2x 10Gbps SFP+ and a PoE budget of 120W. It features innovative near-silent cooling and a 1.3" touch LCM (Liquid Crystal Monitor) to provide status information.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop
Operating System: UniFi
Operating Temperature: -5°C to 45°C
PoE Input: None
PoE Output: 6x 802.3af/at ; 2x 802.3bt
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V to 240V

Dimensions: 200 x 248 x 44mm
Weight: 2.1kg

Ubiquiti's USW-U210 is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget of 202W when powered with the included Power Supply.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (With Included Power Supply)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: -20°C to 60°C (When Powered With Included Power Supply)
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: PoE: 802.3af/at/bt on Port 1 ; DC: 54V, 3.9A
Serial Interface: None
SFP Ports: None
Supported Voltage Range: PoE: 44–57V ; DC: 54V

Dimensions: 203 x 76 x 33 mm
Weight: 1.35kg

Ubiquiti's USW-U60 is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget of 52W when powered with the included Power Supply.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (with included power supply)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: -20°C to 45°C (when powered with included power supply)
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: 802.3af/at/bt on Port 1
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 44–57V

Dimensions: 203 x 76 x 33 mm
Weight: 320kg

Ubiquiti's USW-ULTRA is a compact Layer 2 switch featuring 8 Gigabit Ports with 1x PoE input, 7x PoE output, and a PoE budget dependent on the power source.

It can be configured and managed with the UniFi Network Application.

*Note: Power Supply not included.

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W (Using a Power Supply) 9W (Using a PoE Adapter)
Mounting: Desktop or Wall Mount
Operating System: UniFi
Operating Temperature: PoE++ input: -30 to 60°C ; 60W AC input: -20 to 45°C ; 210W AC input: -20 to 60°C
PoE Input: 802.3af/at/bt
PoE Output: 802.3af/at on Ports 2~8
Power Input: 802.3af/at/bt on Port 1 ; 44-57V DC terminal ; 57V Power Supply (Not Included)
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 44–57V

Dimensions: 203 x 76 x 33 mm
Weight: 320g

Ubiquiti's U7-OUTDOOR is a WiFi 7 outdoor access point featuring 1x 2.5Gbps Ethernet port, versatile wall and pole mounting and is software-switchable from the internal directional antenna to the included external omni antennas. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.
It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Antenna Gain: 2.4GHz : Directional: 8 dBi, Omni: 3 dBi; 5.8GHz : Directional: 12.5 dBi, Omni: 4 dBi
Beam-width: 2.4GHz : 90° ; 5.8GHz : 45°
Data Rate: 2.4GHz : 688Mbps; 5.8GHz : 4.3Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 19W
Mounting: Wall or Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5 to 57V
USB Ports: None

Dimensions: 170 x 208 x 54.5 mm
Weight: 1.2kg

Ubiquiti's U7-PRO-MAX is a Tri-Band, WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding, large scale environments. It delivers an aggregate data rate of up to 15Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.9dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 8.6Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø206 x 46 mm
Weight: 680g

Ubiquiti's U7-PRO-5 offers 5x U7-PRO in a single package. The units are Tri-Band, WiFi 7 access points with 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding environments. It delivers an aggregate data rate of up to 9.3Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.8dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 2.8Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø206 x 46 mm
Weight: 680g

Ubiquiti's U7-PRO is a Tri-Band WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6 GHz support for interference-free WiFi in demanding environments. It delivers an aggregate data rate of up to 9.3Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.
Specifications Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 6dBi : 6GHz: 5.8dBi
Beam-width: 360
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 2.8Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 21W
Mounting: Ceiling or Wall Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: Ø206 x 46 mm
Weight: 680g

Ubiquiti's U7-PRO-IW is a Tri-Band, WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6GHz support for interference-free WiFi in demanding, large scale environments. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2x2 MU-MIMO) 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

Specifications

Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi : 6GHz: 6dBi
Beam-width: 360°
Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 4.3Gbps ; 6GHz: 5.7Gbps
Ethernet Ports: 1x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: 1 Gang Electrical Wall Box (Not Included)
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3at or Passive PoE
PoE Output: None
Power Input: 802.3at or Passive PoE (Not Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44 to 57V
USB Ports: None

Dimensions: 150 x 103 x 36 mm
Weight: 580g

Ubiquiti’s U6-MESH is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point with a compact IPX5 indoor/outdoor enclosure. It delivers an aggregate data rate of up to 5.3 Gbps over its 5GHz (4x4 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

Antenna Gain: 2.4GHz: 3dBi ; 5.8GHz: 5dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 4800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11.4W
Mounting: Desktop ; Wall-Mount ; Pole Mount ; Ceiling Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af PoE
PoE Output: None
Power Input: 48V; 0.32A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44V-57V
USB Ports: None

Dimensions: Ø 48.50 x 159.49mm
Weight: 400g

Ubiquiti’s U6-MESH-PRO is an indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point featuring 2x Gigabit Ethernet ports, 4 spacial streams and integrated high power 8dBi antennas. It delivers an aggregate data rate of up to 3Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.

Note: It can be configured and managed with the UniFi Network Application.
Antenna Gain: 2.4GHz: 8dBi ; 5.8GHz: 8dBi
Beam-width: 360°
Data Rate: 2.4GHz: 574Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Desktop ; Wall-Mount ; Pole Mount
Operating System: UniFi
Operating Temperature: -30°C to 60°C
PoE Input: 802.3af/at PoE
PoE Output: None
Power Input: 48V; 0.5A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 42.5V-57V
USB Ports: None

Dimensions: 343.2 x 181.2 x 60.2 mm
Weight: 819g
