UltraLAN Fiber Pigtail - SC APC SM Simplex 0.9m

UltraLAN Fiber Pigtail - SC APC SM Simplex 0.9m

UltraLAN fiber optic pigtails provide a fast way to make communication links in the field, and are also commonly used for termination inside patch panels and termination boxes. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet the most stringent mechanical and performance specifications.

Connector A SC Connector B Unterminated
Fiber Mode 9/125 μm Fiber Count Simplex
Fiber Grade G.652.D Minimum Bend Radius 30 mm
Polish Type APC Wavelength 1310 nm/1550 nm
Insertion Loss ≤0.3 dB Return Loss ≥60 dB
