Ubiquiti's WAVE-NANO is a 60GHz radio system with an integrated high-gain antenna, GPS, and a 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 12 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 5km) or WAVE-APM (4km) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For PtP links, firmware v.3.2.0 or later is required.

Antenna Gain: 60GHz: 41dBi ; 5.8GHz: 19dBi
Beamwidth: 60GHz: 1° ; 5GHz: 17°
Data Rate: 60GHz: Up to 2Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V or 48V
USB Ports: None

Dimensions: Ø256.5 x 113.5 mm
Weight: 1.2kg

Ubiquiti's WAVE-PICO is a 60GHz radio system with an integrated high-gain antenna, and a WiFi 6, 5GHz backup radio. It features Wave technology with true duplex gigabit performance PtP links up to 3km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 1.3km) or WAVE-APM (900m) with a total throughput of up to 2Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For PtP links, firmware v.3.2.0 or later is required.
Antenna Gain: 60GHz: 27.7dBi ; 5.8GHz: 9dBi
Beamwidth: 60GHz: 6° ; 5GHz: 50°
Data Rate: 60GHz: Up to 2Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V or 48V Passive PoE
PoE Output: None
Power Input: 48V 0.5A, Gigabit PoE Injector (Included)
Serial Interface: None
SFP Ports: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V Passive PoE
USB Ports: None

Dimensions: Ø152.1 x 55.8 mm
Weight: 347g

Ubiquiti's WAVE-PRO is a high-capacity 60GHz radio system with 5GHz backup radio, an integrated high-gain antenna, 2x 2.5Gbps Ethernet Ports, 1x 10Gbps SFP+ as well as integrated GPS and precision mount bracket. It features Wave technology with true duplex gigabit performance PtP links up to 15 km. In PtMP mode, it can be used as a CPE and paired with the WAVE-AP (up to 8km) or WAVE-APM (6km) with a total throughput of up to 5.4Gbps.

Also included is a built-in Bluetooth management radio for easy setup via the UISP network management platform. An alignment tool is included with the unit to assist with accurate and reliable aligning of the antennas.

*Note: For PtP links, firmware v.3.2.0 or later is required.
Antenna Gain: 60GHz: 46dBi ; 5.8GHz: 22dBi
Beamwidth: 60GHz: 1.3° ; 5GHz: 8°
Data Rate: 60GHz: Up to 5.4Gbps ; 5.8GHz: 800Mbps
Ethernet Ports: 2x 10/100/1000/2500
Hardware Button: Reset
Max. Power Consumption: 26W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 44–54V or 22–27V Passive PoE
PoE Output: None
Power Input: 48V 0.65A Gigabit PoE Injector (included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44–54V or 22–27V
USB Ports: None
Other: 1x SFP+

Dimensions: Ø424.4 x 166.2mm
Weight: 4kg

Ubiquiti's UISP-CON is a UISP Console with the pre-installed UISP application which features a built-in switch with 8x Gigabit Ethernet Ports and 1x 10Gbps SFP+ Port. It also offers 1x 10Gbps SFP+ and 1x Gigabit Ethernet WAN connections and can be wall or rack mounted with the included kit.
Ethernet Ports: 8x 10/100/1000 (LAN) 1x 10/100/1000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop, Wall or Rack-Mount
Operating System: UISP
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: None
Power Input: 24V 2.5A power supply (Included)
Processor: Quad-Core 1.7 GHz ARM® Cortex®-A57
Serial Interface: None
SFP Ports: 1x 10Gbps (LAN) 1x 10Gbps (WAN)
Supported Voltage Range: 24-28V
System Memory: 4 GB DDR4
USB Ports: None
Other: 1x MicroSD card slot

Dimensions: 210.4 x 140.2 x 43.7 mm
Weight: 1.5kg

Ubiquiti's ER-6P is a professional 5 port Gigabit Ethernet router with SFP connectivity. Based on EdgeOS, it contains a quad-core, 1Ghz processor and 24v PoE out. It is designed for ISP (internet service provider) or SME (small to medium enterprise) deployments which require advanced routing features. It can be managed via the UISP network management platform.
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 16W
Mounting: Wall Mount or Desktop
Operating System: EdgeMAX
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 24V Passive PoE Output on Ports 0~4
Power Input: 24V 2.5A Power Supply (Included)
Processor: 4-Core 1GHz; MIPS64
Serial Interface:1x RJ45 Serial Port
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 16 - 30VDC
System Memory: 1GB DDR3 RAM
USB Ports: 1x USB 3

Dimensions: 229 x 136.5 x 31.1 mm
Weight: 730 g

Ubiquiti's ES24-250 is a managed 24 port Gigabit PoE switch with SFP connectivity. It features 802.3af/at PoE as well as passive 24v PoE on all Ethernet ports with a maximum budget of 230W. L2/L3 functionality makes them suitable for a wide range of high performance applications. It can be managed via the UISP network management platform.

Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Desktop or Rack-Mount
Operating System: EdgeMAX
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at or 24V Passive PoE on Ports 1~24
Power Input: 1x IEC Power Cord (Included)
Serial Interface: 1x RJ45 Ethernet In/Out Band
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100V-240V

Dimensions: 485 x 43.7 x 285.4mm
Weight: 4.7Kg

Ubiquiti's ES48-500 is a managed 48 port Gigabit PoE switch with SFP+ connectivity. It features 802.3af/at PoE as well as passive 24v PoE on all Ethernet ports with a maximum budget of 436W. L2/L3 functionality makes them suitable for a wide range of high performance applications. It can be managed via the UISP network management platform.

Ethernet Ports: 48x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 64W
Mounting: Desktop or Rack-Mount
Operating System: EdgeMAX
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: 802.3af/at or 24V Passive PoE on Ports 1~48
Power Input: 1x IEC Power Cord (Included)
Serial Interface: 1x RJ45 Ethernet In/Out Band
SFP Ports: 2x 10Gbps ; 2x 1.25Gbps
Supported Voltage Range: 100V-240V

Dimensions: 485 x 43.7 x 374.6mm
Weight: 6.1Kg

Ubiquiti's ES8-150 is a managed 8 port Gigabit PoE switch with SFP connectivity. It features 802.3af/at PoE as well as passive 24v PoE on all Ethernet ports with a maximum budget of 130W. L2/L3 functionality makes them suitable for a wide range of high performance applications. It can be managed via the UISP network management platform.
Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 20W
Mounting: Desktop
Operating System: EdgeMAX
Operating Temperature
PoE Input: None
PoE Output: 802.3af/at or 24V Passive PoE on Ports 1~8
Power Input: 1x IEC Power Cord (Included) Or 42V to 56V DC input with Terminal Block
Serial Interface: 1x RJ45 Ethernet In/Out Band
SFP Ports: 2x 1.25Gbps
Supported Voltage Range: 100V-240V

Dimensions: 204 x 43 x 235mm
Weight: 1.8Kg

Ubiquiti's UF-OLT-4 is a fibre solution that anyone can deploy. No command lines, manuals or paid support licenses are required. UISP offers internet and telecom service providers a cost-effective fibre optic delivery system for Triple Play Services (data, voice, IPTV/VoD). The UISP Fiber OLT 4 features four PON ports to connect up to 512 ONUs. The SFP+ port delivers up to 10 Gbps of uplink connectivity. The 1U-high metal chassis allows for convenient mounting in a standard-sized, 19" wide rack.

It can be managed via the UISP network management platform.

*Note: 1x UF-GP-B+ included.
Ethernet Ports: None
Hardware Button: Reset
Max. Power Consumption: 35W
Mounting: Rack-Mount
Operating System: UFiber
Operating Temperature: -10°C to 45°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included) ; 24VDC (Not Included)
Processor: MIPS 1004kc; 880 MHz Dual Core
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 4x 2.5/1.25Gbps GPON Ports ; 1x 10Gbps
Supported Voltage Range: 24V or 100V – 240V
System Memory: 512 MB DDR3; 512 MB NAND
USB Ports: 1x USB 2.0

Dimensions: 299.80 x 258.95 x 42.55mm
Weight: 2.13kg

Ubiquiti's UF-LOCO is a robust, high-performance GPON CPE that features extremely low power consumption and a choice of 24V passive PoE or Micro-USB power methods. It supports GPON links of up to 20km. The UF-LOCO integrates with the UF-OLT4 and UF-OLT and provides powerful Layer 2/3 management features.

It can be managed via the UISP network management platform.

For third-party compatibility, Ubiquiti has provided the following guide: OLT Compatibility Guide.(https://help.ui.com/hc/en-us/articles/115009335068-UISP-Fiber-Supported-Third-Party-OLTs)
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 3.5W
Mounting: Desktop
Operating System: UFiber
Operating Temperature: -10°C to 45°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 5V 1A Micro USB Power Supply (Included)
Processor: MIPS32; 240 MHz
Serial Interface: None
SFP Ports: 1x 2.5/1.25Gbps SC APC GPON
Supported Voltage Range: 24V Passive PoE or 4.7 – 5.3VDC
System Memory: 128 MB DDR3
USB Ports: None

Dimensions: 76.5 x 76.5 x 26.4mm
Weight: 77g

Ubiquiti's UF-WIFI6 is a dual band, WiFi 6 (802.11ax) GPON CPE. It features an LED display, 4x Gigabit Ethernet Ports, 1xSC APC GPON WAN port and provides powerful Layer 2/3 management features. The unit is capable of distances of up to 20km with speeds of up to 2.4Gbps downstream and 1.2Gbps upstream. The UF-WIFI6 can be powered by either the included 5V 3A USB-C or 24V Passive PoE.

It can be managed via the UISP network management platform.

Antenna Gain: 2.4GHz: 1dBi ; 5.8GHz: 3dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 1.2Gbps
Ethernet Ports: 4x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: UFiber
Operating Temperature: -15°C to 45°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 5V 3A USB-C (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 10-30V Passive PoE ; 5VDC USB-C
USB Ports: None
Other: 1x 2.5/1.25Gbps SC APC GPON

Dimensions: 140.8 x 141.5 x 31.65 mm
Weight: 415g

Ubiquiti's UF-WIFI is a robust, high-performance GPON CPE. It features an LED display, 4x Gigabit Ethernet ports, 1x SC APC port and 2.4GHz WiFi connectivity. It provides powerful Layer 2/3 management features. The unit can be powered using 24V Passive PoE on Port 1, or by a 24V power supply.

It can be managed via the UISP network management platform.
Antenna Gain: 1dBi
Beam-width: 360°
Data Rate: 300Mbps
Ethernet Ports: 4x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7W
Mounting: Desktop
Operating System: UFiber
Operating Temperature: -10°C to 45°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20V-28V
USB Ports: None
Other: 1x 2.5/1.25Gbps SC APC GPON

Dimensions: 126.34 x 126.09 x 31.65mm
Weight: 190g

Ubiquiti's LTU-INS is a 5.8GHz integrated feed featuring proprietary LTU technology, supplied in a 5-Pack with PoE Injectors included. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz). Its custom LTU silicon and radio architecture provide up to 900Mbps of real TCP/IP throughput.

The unit functions in either a Point-to-Point (PtP) or Point-to-Multipoint (PtMP) environment with the LTU-ROCKET as its base station. The feed design allows for quick and easy conversion of existing LBE-523ACG2 to a 22dBi LTU CPE.

It can be managed via the UISP network management platform.

*Note: PtP mode requires firmware versions 1.5.1 or later. For maximum throughput firmware version 2.3.0 or later is required.

Antenna Gain: 22dBi
Beam-width: 15°
Data Rate: Up to 900Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22 - 26V
USB Ports: None

Dimensions: 201.46 x 64.15 x 56.15mm
Weight: 215g

Ubiquiti's LTU-LR is a 5GHz, 26dBi, integrated radio featuring proprietary LTU technology. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz). Its custom LTU silicon and radio architecture provide up to 900+ Mbps of real TCP/IP throughput. It can be managed via the UISP network management platform.

*Note: PtP mode requires firmware versions 1.5.1 or later. For maximum throughput firmware version 2.3.0 or later is required.
Antenna Gain: 26dBi
Beam-width: 15°
Data Rate: Up to 550Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40 to 60° C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22 - 26V
USB Ports: None

Dimensions: 512.5 x 385.75 x 258.3 mm
Weight: 1.73kg

Ubiquiti's LTU-LITE is a 5GHz, 13dBi integrated radio featuring proprietary LTU technology. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz). Its custom LTU silicon and radio architecture provide up to 900+ Mbps of real TCP/IP throughput. It can be managed via the UISP network management platform.

*Note: PtP mode requires firmware versions 1.5.1 or later. For maximum throughput firmware version 2.3.0 or later is required.
Antenna Gain: 13dBi
Beam-width: 45°
Data Rate: Up to 550Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount & Wall-Mount
Operating System: airOS
Operating Temperature: -40°C to 55°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22V-26V
USB Ports: None

Dimensions: 153 x 84 x 39.5mm
Weight: 250g

Ubiquiti's LTU-PRO is a 5GHz, 24dBi, integrated radio featuring proprietary LTU technology. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz). Its custom LTU silicon and radio architecture provide up to 900+ Mbps of real TCP/IP throughput. It can be managed via the UISP network management platform.

*Note: PtP mode requires firmware versions 1.5.1 or later. For maximum throughput firmware version 2.3.0 or later is required.
Antenna Gain: 24dBi
Beam-width: 14°
Data Rate: Up to 550Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 60°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22V-26V
USB Ports: None

Dimensions: 316.5 x 316.5 x 174.3mm
Weight: 1.3kg

Ubiquiti's LTU-ROCKET is a connectorised radio featuring proprietary LTU technology. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM. and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz ). Its custom LTU silicon and radio architecture provide up to 900+ Mbps of real TCP/IP throughput. It can be managed via the UISP network management platform.

*Note: For maximum throughput firmware version 2.3.0 or later is required.
Antenna Gain: Antenna Dependent (2x RP SMA Female)
Beam-width: Antenna Dependent
Data Rate: Up to 600Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 25W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 55°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 1A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 244 x 82 x 48mm
Weight: 468g

Ubiquiti's LTU-XR is a 5GHz, 29dBi, integrated radio featuring proprietary LTU technology. This technology is not impeded by the limitations of standard 802.11 WiFi technology, supporting 1024QAM and offering Channel Width Flexibility (10/20/30/40/50/60/80/100 MHz). Its custom LTU silicon and radio architecture provide up to 900+ Mbps of real TCP/IP throughput. It can be managed via the UISP network management platform.

*Note: PtP mode requires firmware versions 1.5.1 or later. For maximum throughput firmware version 2.3.0 or later is required.
Antenna Gain: 29dBi
Beam-width: 3 dB: 5.5°, 6 dB: 7.5° (Horizontal & Vertical)
Data Rate: Up to 550Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 55°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 22V-26V
USB Ports: None

Dimensions: 747 x 525 x 347mm
Weight: 3.2kg

Ubiquiti's UISP-R is a router featuring 8x Gigabit PoE ports, 1x SFP and a PoE budget of 110W when powered with the included Power Supply. Its dual-core, 880Mhz processor is ideal for MicroPoP applications and can be managed via the UISP network management platform.

Ethernet Ports: 8x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Desktop or Outdoors with the UISP-BOX
Operating System: UISP
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 27V Passive PoE Output on Ports 1~8
Power Input: 27V, 4.4A Power Supply (Included)
Processor Dual-core 880 MHz, MIPS1004Kc
Serial Interface: None
SFP Ports: 1x 1.25Gbps
Supported Voltage Range: 24-28V
System Memory: 512 MB DDR3
USB Ports: None

Dimensions: 210.4 x 95 x 29 mm
Weight: 600g

Ubiquiti's UISP-RPRO is a professional router featuring 9x Gigabit Ethernet ports, and 4x 10Gbps SFP+ ports. Its quad-core 1.7GHz processor is ideal for ISP applications and can be managed via the UISP network management platform.
Ethernet Ports: 8x 10/100/1000 (LAN) ; 1x 10/100/1000 (WAN)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Desktop
Operating System: UISP
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cable (Included)
Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100-240V
System Memory: 4 GB DDR4
USB Ports: None

Dimensions: 442.4 x 200 x 43.7 mm
Weight: 3.3kg
