MikroTik's RB-CHATLTE6 is an indoor, dual band WiFi 5 router with 5x Gigabit Ethernet Ports and LTE6 support. The wireless router offers speeds of up to 1200Mbps. With carrier aggregation, which uses multiple bands simultaneously, the CAT6 modem delivers up to 300Mbps.

Note: The SMA Female connectors on the back of the device are for connecting external LTE antennas. Should you wish to add external WiFi antennas, UFL to RP SMA Female pigtails will need to be installed.
Antenna Gain: LTE: 4dBi Wireless: 2.4GHz: 2dBi ; 5GHz: 4dBi
Beam-width: 360°
Data Rate: LTE: 300Mbps Downlink 50Mbps Uplink Wireless: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop
Operating System: RouterOS v7 (Level 4 License)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Serial Interface: None
SIM Slots: 1x Micro SIM
Supported Voltage Range: 12V-28V
USB Ports: 1x Type A

Dimensions: 240 x 156 x 44 mm

MikroTik's RB-CHATAX is an indoor WiFi 6 Router featuring a quad core ARM 64bit 2.2GHz CPU, 5x Gigabit Ethernet Ports, 1x PoE output, 4x4 Mu-MIMO and an aggregate data rate of up to 3600Mbps.
ntenna Gain: 2.4GHz: 5dBi ; 5.8GHz: 6Bi
Beam-width: 360°
Data Rate: 2.4GHz: 1148Mbps ; 5.8GHz: 2400Mbps
Ethernet Ports: 5x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 18W
Mounting: Desktop
Operating System: RouterOS, License level 6
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: Passive PoE Passthrough
Power Input: 48V 1.35A Power Supply (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18-57V
USB Ports: 1x USB 3.0

Dimensions: 240 x 156 x 44 mm

MikroTik's RB-CCR2116P features 16 cores, each with 2GHz processing power, 12 Gigabit Ethernet Ports, 4 x 10Gbps SFP+ uplink ports and a dual redundant power supply. The router supports Layer 3 Hardware Offloading and each group of 4 Ethernet ports has a separate full-duplex connection to the switch chip to prevent bottlenecks.
Ethernet Ports: 12x 10/100/1000 ; 1x 10/100/1000 Management Interface
Hardware Button: Reset
Max. Power Consumption: 60W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 1x M.2 slot

Dimensions: 443 x 199 x 44mm

MikroTik's RB-CCR2004 is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 12x 10Gbps SFP+ ports, 2x 25Gbps SFP28 ports and dual power supplies for integrated redundancy.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 32W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 10Gbps ; 2x 25Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None

Dimensions: 443 x 224 x 44mm

MikroTik RB-CCR2216SP features 16 cores, 12x SFP28 25Gbps ports, 2x QSFP28 100Gbps ports, and a Gigabit Ethernet port. The device includes 2x M.2 SATA slots for additional storage as well as 4x hot-swappable fans and dual-redundant hot-swap power supplies.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 80W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 16 core 2GHz AL73400
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 12x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 16GB
USB Ports: None
Other: 2x M.2 slots

Dimensions: 443 x 367 x 44mm

MikroTik's RB-CCR2004P is a carrier-grade cloud core router powered by a 4 core ARM CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and dual power supplies for integrated redundancy. Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch chip. Each switch chip has a 10Gbps full-duplex line connected to the CPU. Each SFP+ cage also has a separate 10Gbps full-duplex line.
Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 35W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 4 core 1.7GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 4GB
USB Ports: None

Dimensions: 443 x 210 x 44mm

MikroTik's RB-CCR2004PC is a carrier-grade Cloud Core router powered by a 4-core ARM64 CPU. The unit comes equipped with installed RouterOS L6 and 4GB of onboard RAM. It features 16x Gigabit Ethernet ports as well as 2x SFP+ uplink ports and can be powered by either the DC Jack or a 2-pin terminal connection. Each group of 8x Gigabit Ethernet ports is connected to a separate switch chip which has a 10Gbps full-duplex line connected to the CPU. The SFP+ Ports also have a separate 10Gbps full-duplex line to prevent bottlenecks.
Ethernet Ports: 16x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: RouterOS v7 Only (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 36V-57V DC Jack or 2 Pin Terminal
Processor: 4 core 1.2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Console Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 36V-57V
System Memory: 4GB
USB Ports: None

Dimensions: 272 x 195 x 44mm

MikroTik's RB-CCR2004PCIE is a 4-core ARM64 CPU, smart PCIe network interface card (NIC) that adds fully-fledged router capabilities to your Linux servers or PCs. It features 2x SFP28 25Gbps SFP ports and 1x Gigabit Ethernet Port for management.

Note: The device is supported in Linux (minimum kernel 5.15.25) and RouterOS (minimum version 7.x), but it will not be recognised in Windows.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 22W
Mounting: Low Profile & High Bracket (Included)
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: PCI-e
Processor: 4 core 2GHz AL32400 ARM 64bit
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 25Gbps
System Memory: 4GB
USB Ports: None

Dimensions: 170 x 69 x 18mm

MikroTik's RB-CRS320P is a Cloud Router Switch with 16x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 600W. PoE ports 1 to 8 support PoE+ (802.3af/at) and ports 9 to 16 support PoE++ (802.3af/at/bt). The unit includes a hot-swappable PSU as well as an expansion slot for an additional PSU, which can raise the PoE budget to 1150W.
Ethernet Ports: 17x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 36W
Mounting: Rack-Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -10°C to 50°C
PoE Input: None
PoE Output: 802.3af/at on Ports 1 to 8 : 802.3af/at/bt on Ports 9 to 16
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX226S
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 256MB
USB Ports: None
Other: None

Dimensions: 444 x 235 x 44 mm

MikroTik's RB-CRS317 is a Cloud Router Switch featuring 16x SFP+ ports and 1x Gigabit Ethernet Port for management. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or RouterOS with a Level 6 License.
Ethernet Ports: 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 44W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 6 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included)
Processor: 2 Core 800MHz 98DX8216
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 16x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 1GB
USB Ports: None
Other: None

Dimensions: 443 x 224 x 44mm

MikroTik's RB-CRS518S is a Cloud Router Switch featuring 16x 25Gbps SFP28 ports, 2x 100Gbps QSFP28 ports with a total of 1.2Tbps switching capacity. The router has dual power supplies for power redundancy. The 25Gbps SFP28 ports are backwards compatible with 10Gbps and 1.25Gbps SFP modules while the 100Gbps QSFP28 ports are also compatible with the 40Gbps QSFP modules.
Ethernet Ports: 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 45W
Mounting: Rack-Mount
Operating System: RouterOS (Level 6 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: None
PoE Output: None
Power Input: 2x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 16x 25Gbps ; 2x 100Gbps
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: 1x USB
Other: None

Dimensions: 443 x 265 x 44.5 mm

MikroTik's RB-CRS328S is a Cloud Router Switch featuring 20x 1.25Gbps SFP ports, 4x 10Gbps SFP+ ports and 4x SFP or Gigabit Ethernet combo ports. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 4x 10/100/1000 (4 Combo Ports)
Hardware Button: Reset; Mode
Max. Power Consumption: 43W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 800MHz 98DX3236
Serial Interface:1x RJ45 Serial Port
SFP Ports: 24x 1.25Gbps (4 Combo Ports); 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 443 x 200 x 44mm

MikroTik' s CRS326 is a Cloud Router Switch featuring 24x Gigabit Ethernet Ports, 2x 10Gbps SFP+ ports and 1x Gigabit Ethernet port for either management or PoE Input. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 24x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 24W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 60°C
PoE Input: 10V-30V (Passive PoE)
PoE Output: None
Power Input: 24V 1.2A Power Supply (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 2x 10Gbps
Supported Voltage Range: 10V-30V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 440 x 144 x 44mm

MikroTik's RB-CRS328 is a Cloud Router Switch featuring 24x Gigabit PoE ports, 4x 10Gbps SFP+ ports and a PoE budget of 450W. The 24 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 24x10/100/1000
Hardware Button: Reset; Mode
Max. Power Consumption: 44W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3af/at or 26V Passive PoE on Ports 1~24
Power Input: Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 800MHz 98DX3236
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps
Supported Voltage Range: 100V-240V
System Memory: 512MB
USB Ports: None
Other: None

Dimensions: 443 x 305 x 44mm

MikroTik's RB-CRS326Q is a Cloud Router Switch featuring 24x 10Gbps SFP+ Ports and 2x 40Gbps QSFP+ ports. The Router has dual power supplies for power redundancy and a full-sized USB port for configuration. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 42W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: Power Input: 2x IEC Power Cord (Included) (Dual Internal PSU)
Processor: 1 Core 650MHz QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 24x 10Gbps ; 2x 40Gbps QSFP
Supported Voltage Range: 100-240V
System Memory: 64MB
USB Ports: 1x USB 2.0
Other: None

Dimensions: 443 x 200 x 44mm

MikroTik's RB-CRS304XG is a Cloud Router Switch featuring 4x 10Gbps Ethernet Ports and 1x Gigabit Management Port. This switch includes a convenient DIN rail mount on the side and standard screw attachment points on the back. It also offers 4 different power inputs, 2x DC jacks, a 2-pin terminal, and PoE-input. The switch automatically selects the power source with the highest voltage, ensuring uninterrupted operation.
Ethernet Ports: 4x 10Gbps : 1x 10/100/1000 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 15W
Mounting: Desktop or DIN Rail Mount
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at
PoE Output: None
Power Input: 48V 0.95A Power Supply
Processor: Dual Core 1200MHz 98DX2528
Serial Interface: None
SFP Ports: None
Supported Voltage Range: 36-57V (PoE) 12-57V (DC Input)
System Memory: 512MB
USB Ports: None
Other: Terminal DC Input

Dimensions: 176 x 128 x 35 mm

MikroTik's RB-CRS305S is a Cloud Router Switch featuring 4x 10Gbps SFP+ Ports, 1x Gigabit Ethernet port for management and dual DC Jacks for power redundancy. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.

*Note: In order to achieve the best compatibility, MikroTik recommends not using grounding when powering this device with 802.3af/at.
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 12W
Mounting: Desktop
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -40°C to 70°C
PoE Input: 802.3af/at or 12-57V Passive PoE
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included) (Dual DC input for power redundancy)
Processor: 1 Core 800 MHz 98DX3236
Serial Interface: None
SFP Ports: 4x 10Gbps
Supported Voltage Range: 12-57V
System Memory: 512MB
USB Ports: None

Dimensions: 141 x 115 x 28mm

MikroTik's RB-CRS354Q is a Cloud Router Switch featuring 48x Gigabit Ethernet ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports and 1x Fast Ethernet Management port. The Router has dual power supplies for power redundancy and supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 48x 10/100/1000 : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 50W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Processor: 1 Core 650 MHz QCA9531
Serial Interface:1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64MB
USB Ports: None
Other: None

Dimensions: 297 x 443 x 44mm

MikroTik's RB-CRS354QP is a Cloud Router Switch featuring 48x Gigabit PoE Ports, 4x 10Gbps SFP+ ports, 2x 40Gbps QSFP+ ports, 1x Fast Ethernet Management port and a PoE budget of 700W. The 48 Gigabit PoE ports offer both Passive PoE and auto-sensing 802.3af/at PoE. The unit supports the dual boot function which supports either SwOS or RouterOS with a Level 5 License.
Ethernet Ports: 48x 10/100/1000 : 1x 10/100 (Management Port)
Hardware Button: Reset
Max. Power Consumption: 85W
Mounting: Rack-Mount
Operating System: Dual Boot - SwOS or RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 60°C
PoE Input: None
PoE Output: 802.3at/af ; 26V or 53V Passive PoE
Power Input: 1x IEC Power Cord (Included)
Processor: QCA9531
Serial Interface: 1x RJ45 Serial Port
SFP Ports: 4x 10Gbps ; 2x QSFP+
Supported Voltage Range: 100V-240V
System Memory: 64 MB
USB Ports: None
Other: None

Dimensions: 443 x 382 x 44mm

MikroTik's RB-CRS106 is a Cloud Router Switch featuring 5x 1.25Gbps SFP ports, 1x 1.25Gbps SFP or PoE Input Combo Port and is powered by RouterOS with a Level 5 license.
Ethernet Ports: 1x 10/100/1000 (Combo Port)
Hardware Button: Reset
Max. Power Consumption: 11W
Mounting: Desktop
Operating System: RouterOS (Level 5 Licence)
Operating Temperature: -20°C to 70°C
PoE Input: 11V-30V (Passive PoE Combo Port)
PoE Output: None
Power Input: 24V 0.8A Power Supply (Included)
Processor: 1 Core 400MHz QCA8511
Serial Interface:1x RJ45 Serial Port
SFP Ports: 6x 1.25Gbps (1x Combo Port)
Supported Voltage Range: 11V-30V
System Memory: 128MB
USB Ports: None
Other: None

Dimensions: 114 x 137 x 29mm
