Ubiquiti's LOCO-5ACL is an airMAX AC 5GHz radio with a 13dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) solution or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: The LOCO-5ACL does not ship with a PoE adapter; we recommend powering the unit with our UPOE-24G12W
Antenna Gain: 13dBi
Beam-width: 45°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V Passive PoE
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 179 x 77.5 x 59.1mm
Weight: 180g

Ubiquiti's LOCO-M2 is an airMAX M series 2GHz radio with a 10dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) access point solution. It can be managed via the UISP network management platform.
Antenna Gain: 8.5dBi
Beam-width: 60°
Data Rate: 150Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 5.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -30°C to 75°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 161 x 31 x 80mm
Weight: 180g

Ubiquiti's NBE-213AC is an airMAX AC 2GHz radio with a 13dBi antenna. It is designed as a lightweight, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 13dBi
Beam-width: 60°
Data Rate: 450Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7.5W
Mounting: Pole-Mount
Operating System: airMAX
Operating Temperature: -40°C to 80°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 189 x 189 x 125mm
Weight: 530g

Ubiquiti's NBE-519ACG2 is an airMAX AC 5GHz radio with a 19dBi antenna. It is designed as a lightweight, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) solution. It features 24v passive PoE pass-through. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 19dBi
Beam-width: 30°
Data Rate: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 80°C
PoE Input: 24V Passive PoE
PoE Output: 24V Passive PoE Pass-Through
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 189 x 189 x 125mm
Weight: 530g

Ubiquiti's NBE-516 is an airMAX M series 5GHz radio with a 16dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) access point solution. It can be managed via the UISP network management platform.
Antenna Gain: 16dBi
Beam-width: 30°
Data Rate: 300Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 140 x 140 x 54mm
Weight: 320g

Ubiquiti's NS-5AC is an airMAX AC 5GHz radio with a 16dBi antenna. It is designed as a lightweight, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) solution. It features 24v or 48v passive PoE pass-through. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

Antenna Gain: 16dBi
Beam-width: 45°
Data Rate: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE; 802.3af Active PoE
PoE Output: PoE Passthrough.
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V; 36V-57V
USB Ports: None

Dimensions: 257 x 84 x 30mm
Weight: 233g

Ubiquiti's NSM5 is an airMAX M series 5GHz radio with a 16dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) or PtMP (point to multipoint) access point solution. It can be managed via the UISP network management platform.
Antenna Gain: 16dBi
Beam-width: 41°
Data Rate: 300Mbps
Ethernet Ports: 2x 10/100
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -30°C to 75°C
PoE Input: 24V Passive PoE
PoE Output: 24V Passive PoE Pass-through
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 294 x 31 x 80mm
Weight: 400g

Ubiquiti's PBE-218AC is an airMAX AC 2GHz radio with an 18dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 18dBi
Beam-width: 20°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 7.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 420 x 420 x 289mm
Weight: 1.795kg

Ubiquiti's PBE-525ACISO is an airMAX AC 5GHz radio with a 25dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. The isolator/radome cover provides better antenna shielding and protects it in harsh environments. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 25dBi
Beam-width: 12°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20V-26V
USB Ports: None

Dimensions: 459 x 459 x 261mm
Weight: 3.2kg

Ubiquiti's PBE-525ACG2-5 is an airMAX AC 5GHz radio with 25dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 25dBi
Beam-width:12°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20V-26V
USB Ports: None

Dimensions: 420 x 420 x 230mm
Weight: 2.22kg

Ubiquiti's PBE-525ACG2 is an airMAX AC 5GHz radio with 25dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.
Antenna Gain: 25dBi
Beam-width: 12°
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20V-26V
USB Ports: None

Dimensions: 420 x 420 x 230mm
Weight: 2.22kg

Ubiquiti's PBE-522 is an airMAX M series 5GHz radio with 22dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. It can be managed via the UISP network management platform.
Antenna Gain: 22dBi
Beam-width: 18°
Data Rate: 300Mbps
Ethernet Ports: 1x 10/100
Hardware Button: Reset
Max. Power Consumption: 6W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Passive PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 325 x 325 x 256mm
Weight: 1.203kg

Ubiquiti's PBE-525 is an airMAX M series 5GHz radio with 25dBi antenna. The dish reflector provides the best antenna performance due to its high directivity and interference rejection characteristics. It is designed as a high-performance, long-distance CPE (client premises equipment) or PtP (point-to-point) solution. It can be managed via the UISP network management platform.
Antenna Gain: 25dBi
Beam-width:12°
Data Rate: 300Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 24V
USB Ports: None

Dimensions: 420 x 420 x 275mm
Weight: 1.753kg

Ubiquiti's ROCKETAC-LITE airMAX ac 5GHz radio is designed to work with Ubiquiti's wide range of antennas (sold separately). It can be used as PtMP (point to multipoint) access point in low-moderate interference environments and for high-performance, long-range PtP (point to point) links. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: Antenna not included.
Antenna Gain: Antenna Dependant (2x RP SMA Female)
Beam-width: Antenna Dependant
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 80°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 20V-26V
USB Ports: None

Dimensions: 162 x 84 x 37mm
Weight: 250g

Ubiquiti's R2AC-PRISMG2 airMAX ac 2GHz radio without antennae. Featuring airPrism technology which significantly reduces adjacent channel interference and is designed to work with Ubiquiti's wide range of antennas (sold separately). It can be used as PtMP (point to multipoint) access point in high interference environments or for high-performance, long-range PtP (point to point) links. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: Antenna not included.
Antenna Gain: Antenna Dependant (2x RP SMA Female)
Beam-width: Antenna Dependant
Data Rate: 600Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 70°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 0.5A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18V-26V
USB Ports: None

Dimensions: 88 x 40 x 230mm
Weight: 440g

Ubiquiti’s R5AC-PRISMG2 is an airMAX ac 5GHz radio featuring airPrism technology. The airPrism significantly reduces adjacent channel interference and is designed to work with Ubiquiti’s wide range of antennas. It can be used as PtMP (point-to-multipoint) access point in high interference environments or for high-performance, long-range PtP (point-to-point) links. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: Antenna not included.
Antenna Gain: Antenna Dependant (2x RP SMA Female)
Beam-width: Antenna Dependant
Data Rate: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 9.5W
Mounting: Pole-Mount
Operating System: airOS
Operating Temperature: -40°C to 80°C
PoE Input: 24V Passive PoE
PoE Output: None
Power Input: 24V 1A Gigabit PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 18V-26V
USB Ports: None

Dimensions: 88 x 40 x 230mm
Weight: 400g

Ubiquiti's UAP-ACM is an outdoor, WiFi 5, dual band, 2x2 MIMO access point. It features two detachable antennas that can be exchanged for a different antenna to improve signal propagation. It is capable of reaching up to 1167Mbps aggregate over both 2.4GHz and 5GHz radios.

It can be configured and managed with the UniFi Network Application.
Antenna Gain: 2.4GHz: 2x 3ddBi ; 5.8GHz 2x 4dBi
Beam-width: 360°
Data Rate: 2.4GHz: 300Mbps ; 5.8GHz: 867Mbps
Ethernet Ports: 1x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 8.5W
Mounting: Pole-Mount or Wall-Mount
Operating System: UniFi
Operating Temperature: -30°C to 70°C
PoE Input: 802.3af/at ; 24V/48V Passive PoE
PoE Output: None
Power Input: 24V, 0.5A PoE Injector (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 44V to 57V or 24V
USB Ports: None

Dimensions: 353 x 46 x 34.4mm
Weight: 152g

Ubiquiti's USW-AGG is a fully managed Layer 2 switch with 8x SFP+ ports and up to 160Gbps switching capacity. It features a compact 4.7" depth and fanless design. It is easy to mount and silent even under full load. It provides link aggregation for higher capacity and increased availability. The unit features a 1.3" touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.
Ethernet Ports: None
Hardware Button: Reset
Max. Power Consumption: 30W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 8x 10Gbps+
Supported Voltage Range: 100 to 240VAC

Dimensions: 442.4 x 120 x 43.7 mm
Weight: 2.74kg

Ubiquiti’s USW-AGGPRO is a fully managed Layer 3 switch featuring 28x SFP+ 10Gbps ports and 4x SFP28 25Gbps ports. It is designed to enhance your network’s switching capacity and performance by creating high-bandwidth aggregation links. The rack-mountable switch offers 760Gbps switching capacity and features a 1.3" LCM colour touchscreen.

It can be configured and managed with the UniFi Network Application.

Ethernet Ports: None
Hardware Button: Reset
Max. Power Consumption: 100W
Mounting: Rack-Mount
Operating System: UniFi
Operating Temperature: -5°C to 40°C
PoE Input: None
PoE Output: None
Power Input: 1x IEC Power Cord (Included)
Serial Interface: None
SFP Ports: 28x 10Gbps; 4x 25Gbps
Supported Voltage Range: 100 to 240VAC

Dimensions: 442 x 325 x 44 mm
Weight: 4.7kg

Ubiquiti's UDB is a UniFi Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link. It features 1xGE LAN port that provides 48V 15W PoE output, a 5GHz band with up to 867 Mbps throughput and is compatible with UniFi Protect PoE cameras and various IoT devices via an Ethernet connection. It can be configured and managed with the UniFi Network Application.
Antenna Gain: 5.8GHz: 5dBi (Internal Antenna ) or 4 dBi (External Omni Antenna)
Beam-width: 360°
Data Rate: 5.8GHz: 867Mbps
Ethernet Ports: 2x 10/100/1000
Hardware Button: Reset
Max. Power Consumption: 10W
Mounting: Wall Mount
Operating System: UniFi
Operating Temperature: -10 to 40°C
PoE Input: None
PoE Output: 48V 15W
Power Input: 1x Clover Power Cable (Included)
Serial Interface: None
SIM Slots: None
Supported Voltage Range: 100—240V
USB Ports: None

Dimensions: 130 x 55 x 34 mm
Weight: 200g
